Smeg CPF9IPR Range Cooker

The Smeg CPF9IPR is a 90x60 cm Portofino cooker with a 5-zone induction hob and a large 115 litre thermo-ventilated electric oven. Finished in red with stainless steel details and a flush fit design, it offers A+ energy efficiency, pyrolytic self-cleaning and 20 automatic cooking programmes. With triple fan technology, 10 cooking functions and electronic temperature control, it is designed for flexible, even cooking on up to five levels.

SKU:CPF9IPR

EAN:8017709232283

Category::Freestanding Cookers

Quantity:

Key Features

Cooker size 90x60 cm with 1 cavity and energy label for generous single-oven cooking.

Induction hob with 5 cooking zones including booster functions and pan detection for each zone.

Thermo-ventilated main oven with triple fan technology for uniform heat on all five levels.

Large 115 litre oven capacity (129 l gross) to accommodate substantial dishes.

Pyrolytic self-cleaning system with standard and Eco pyrolytic functions to clean the oven interior.

Energy efficiency class A+ for reduced energy consumption compared with class A.

Portofino aesthetic in red with enamelled metal control panel, coloured handle and black feet and plinth.

TFT display and Smeg Portofino control knobs in stainless steel for clear, precise control.

10 traditional cooking functions plus other functions including defrost by time, defrost by weight, proving and Sabbath.

20 automatic programmes to simplify cooking settings for a range of dishes.

Easy clean enamel cavity with quadruple glazed door and 3 thermo-reflective glasses.

Soft Close oven door with flap-down opening and removable full glass inner door.

Safety features on hob including automatic switch off when overheated, automatic pan detection, minimum pan diameter indication and residual heat indicators.

Electronic temperature control from 50 °C to 260 °C for precise cooking.

Supplied accessories include chrome shelf, two trays, grill mesh and partial telescopic guide rails.

Compatible accessories available such as Airfry rack, BBQ grid, enamelled trays, griddle and universal plates.

Flush fit design with upstand and stainless steel hob colour for a built-in look.

Storage compartment with push-pull opening beneath the oven.

Cooling and safety thermostat including tangential cooling system and door lock during pyrolysis.

Flexible electrical connection options for single, double and three phase installations.

Technical Spec

ModelCPF9IPR

EAN code8017709232283

Cooker size90x60 cm

Number of cavities with energy label1

Cavity heat sourceElectric

Hob typeInduction

Type of main ovenThermo-ventilated

Cleaning system main ovenPyrolytic

Energy efficiency classA+

DesignFlush fit

AestheticsPortofino

ColourRed

Command panel finishEnamelled metal

LogoAssembled st/steel, position: facia below the oven

UpstandYes

Hob colourStainless steel

Type of control settingControl knobs

Control knobsSmeg Portofino, stainless steel, 7 controls, serigraphy colour black

DisplayTFT

DoorWith frame, grey glass, flap down, soft close, removable, full glass inner door, removable inner door

HandleSmeg Portofino, coloured handle

Storage compartmentPush pull

Feet / PlinthFeet black, plinth black

Number of cooking functions10 (traditional cooking functions)

Traditional cooking functionsStatic; Fan assisted; Circulaire; Turbo (circulaire + bottom + upper + fan); ECO; Small grill; Large grill; Fan grill (large); Base; Fan assisted base

Other functionsDefrost by time; Defrost by weight; Proving; Sabbath

Cleaning functionsPyrolytic; Pyrolytic Eco

Automatic programmes20

Total number of cook zones5

Front left zoneInduction, single, 1.40 kW, Booster 2.20 kW, Ø 14.5 cm

Rear left zoneInduction, single, 1.85 kW, Booster 3.00 kW, Ø 18.0 cm

Central zoneInduction, single, 2.60 kW, Booster 3.70 kW, Ø 27.0 cm

Rear right zoneInduction, single, 2.30 kW, Booster 3.70 kW, Ø 21.0 cm

Front right zoneInduction, single, 1.40 kW, Booster 2.20 kW, Ø 14.5 cm

Automatic switch off when overheatYes

Automatic pan detectionYes

Minimum pan diameter indicationYes

Selected zone indicatorYes

Residual heat indicatorYes

Net volume of the cavity115 litres

Gross volume, 1st cavity129 l

Cavity materialEasy clean enamel

Total number of door glasses4 (3 thermo-reflective door glasses)

Shelf positions5

Type of shelvesMetal racks

Number of lights2

Light type / powerHalogen, 40 W

Fan number3

Cooking time settingStart and Stop

Light when oven door is openYes

Heating suspended when door is openedYes

Cooling systemTangential

Door lock during pyrolysisYes

Usable cavity space dimensions (H x W x D)371x724x418 mm

Temperature controlElectronic

Lower heating element power1700 W

Upper heating element power1200 W

Grill element1700 W (large grill 2900 W)

Circular heating element power2 x 1850 W

Grill typeElectric

Soft Close systemYes

TimerYes, with end of cooking acoustic alarm

Minimum temperature50 °C

Maximum temperature260 °C

Accessories included (main oven)1 x chrome shelf with back and side stop; 1 x 20 mm deep tray; 1 x 40 mm deep tray; 1 x grill mesh; 1 x telescopic guide rails, partial extraction

Max power draw11400 W

Current50 A

Voltage220–240 V; 380–415 V (Voltage 2)

Type of electric cableYes, Single phase

Additional connection modalitiesYes, Double and Three Phase

Frequency50/60 Hz

Terminal block5 poles

Overall height (min – max)Not fully specified in text (diagram present); height range indicated around 880–920 mm

Width900 mm

Depth (to front of handle)Not stated in source

Downloads

Download product documentation, manuals, and specification sheets.

CPF9IPR Spec

PDF

Frequently Asked Questions

What is the oven capacity of the Smeg CPF9IPR?

The oven has a net capacity of 115 litres and a gross volume of 129 litres, providing a large single cavity with five shelf positions.

How many induction zones does the hob have and what are their sizes?

The hob has 5 induction zones: two 14.5 cm zones (front left and front right), one 18.0 cm zone (rear left), one 21.0 cm zone (rear right) and one 27.0 cm central zone, each with booster power.

What cleaning options are available for the oven?

The main oven uses a pyrolytic cleaning system with standard and Eco pyrolytic functions. The cavity is finished in easy clean enamel with an antacid lining to reduce grease adherence.

What is the energy rating of this cooker?

The cooker has an energy efficiency class of A+. This class is described as helping to save up to 10% energy compared to class A, with maximum performance and minimum consumption.

Does the cooker have safety features for the hob and oven?

Yes. The hob includes automatic switch off when overheated, automatic pan detection, minimum pan diameter indication and residual heat indicators. The oven provides a safety thermostat, tangential cooling system, heating suspension when the door is opened and a door lock during pyrolysis.

What accessories are supplied with the oven?

Supplied accessories include 1 chrome shelf with back and side stop, 1 x 20 mm deep tray, 1 x 40 mm deep tray, 1 grill mesh and 1 set of partially extractable telescopic guide rails.
