Smeg CPF120IGM Portofino Dual Fuel Range Cooker

The Smeg CPF120IGMPBL is a 120x60 cm Portofino cooker in black with a mixed hob and two thermo-ventilated electric ovens. Designed for flush fit installation, it offers a generous 70 litre main cavity and 63 litre second cavity, both with easy clean enamel interiors. With pyrolytic cleaning for the main oven, Vapor Clean in the second and a range of traditional and Direct Steam functions, it combines flexible cooking with convenient maintenance.

SKU:CPF120IGMPBL

EAN:8017709286064

Category::Freestanding Cookers

Quantity:

Key Features

Cooker size 120x60 cm with Portofino aesthetics in a black finish and flush fit design.

Mixed hob configuration with 6 cook zones including gas burners, induction multizone areas and a Teppanyaki zone.

Two thermo-ventilated electric ovens with 70 litre main cavity and 63 litre second cavity for flexible cooking.

Energy efficient performance with A+ energy efficiency class for the main cavity and A for the second cavity.

Pyrolytic cleaning system in the main oven for easy oven cleaning thanks to a special pyrolytic function.

Vapor Clean system in the second cavity using steam to loosen deposits in the oven cavity.

9 cooking functions in the main oven including Static, Fan assisted, Circulaire, Turbo, ECO, Small grill, Large grill, Fan grill (large) and Fan assisted base.

8 cooking functions in cavity 2 with traditional modes such as Static, Fan assisted, Circulaire, ECO, Large grill, Fan grill (large) and Fan-assisted bottom.

Direct Steam technology in cavity 2 with Termo-ventilato (Circolare + Ventola) steam-assisted cooking.

Easy clean enamel cavities with 5 shelf positions and metal racks in both ovens.

Portofino design details including Smeg Portofino control knobs and handle, black glass and black plinth.

Storage drawer compartment with sliding compartment for storing accessories or cooking utensils.

Touch display timer for easy and intuitive timer setting with a single touch.

Soft Close system on both oven doors for silent and smooth closing.

Safety features including safety thermostat, heating suspended when door is opened and door lock during pyrolysis (main oven).

Automatic electronic gas ignition with standard gas burners and matte black enamelled burner caps.

Induction safety functions including automatic switch off when overheat, automatic pan detection, minimum pan diameter indication, selected zone indicator and residual heat indicator.

Multilevel halogen lighting with 2 halogen lights in each cavity for excellent internal visibility.

Tangential cooling system with airflow from the door to the splashback for safe surface temperatures.

Supplied accessories for each oven including chrome shelf, 20 mm and 40 mm deep trays, grill mesh and telescopic guide rails with total extraction.

Technical Spec

Product codeCPF120IGMPBL

Cooker size120x60 cm

Number of cavities with energy label2

Cavity heat sourceElectric

Hob typeMixed

Type of main ovenThermo-ventilated

Type of second ovenThermo-ventilated

Cleaning system – main ovenPyrolytic

Cleaning system – second cavityVapor Clean

EAN code8017709286064

Energy efficiency class (main)A+

Energy efficiency class (second cavity)A

DesignFlush fit, Portofino aesthetics

ColourBlack

Command panel finishEnamelled metal

LogoAssembled stainless steel, positioned on facia below the oven

UpstandYes

Hob colourStainless steel

Pan standsCast Iron

Type of control settingControl knobs (Smeg Portofino)

Controls colourStainless steel

Number of controls11

Serigraphy colourBlack

DisplayTouch

DoorWith frame, full glass inner door, removable inner door

Glass typeBlack

HandleSmeg Portofino, colour Black

Storage compartmentDrawer with sliding compartment

PlinthBlack

Total number of cook zones6

Left centre zoneGas – 2UR (dual) – 4.20 kW

Front centre zoneGas – Semi Rapid – 1.80 kW

Rear centre zoneGas – Rapid – 3.00 kW

Front right zoneInduction – multizone – 2.10 kW, Booster 2.30 kW, 21.1x19.1 cm

Rear right zoneInduction – multizone – 1.60 kW, Booster 1.85 kW, 21.0x19.0 cm

Central zoneTeppanyaki – 1.40 kW

Number of flexible zones1

Type of gas burnersStandard

Automatic electronic ignitionYes

Burner capsMatte black enamelled

Automatic switch off when overheatYes

Automatic pan detectionYes

Minimum pan diameter indicationYes

Selected zone indicatorYes

Residual heat indicatorYes

Main oven net volume70 litres

Main oven gross volume79 l

Main cavity materialEasy clean enamel

Main oven shelf positions5

Main oven shelves typeMetal racks

Main oven lights2 x Halogen, 40 W

Cooking time setting (main)Start and Stop, timer with end of cooking acoustic alarm

Door opening (main)Flap down

Total door glasses (main)4 (3 thermo-reflective)

Safety thermostat (main)Yes

Heating suspended when door opened (main)Yes

Cooling system (main)Tangential

Door lock during pyrolysisYes

Usable cavity dimensions (main)360x460x425 mm (HxWxD)

Temperature control (main)Electro-mechanical

Heating elements (main)Lower 1200 W; Upper 1000 W; Grill 1700 W; Large grill 2700 W; Circular 2000 W

Grill type (main)Electric

Soft Close (main)Yes

Main oven temperature range50 °C – 280 °C

Second oven net volume63 litres

Second oven gross volume79 l

Second cavity materialEasy clean enamel

Second oven shelf positions5

Second oven shelves typeMetal racks

Second oven lights2 x Halogen, 40 W

Cooking time setting (second)Start and Stop, timer with end of cooking acoustic alarm

Door opening (second)Flap down

Total door glasses (second)3 (2 thermo-reflective)

Cooling system (second)Tangential

Usable cavity dimensions (second)360x460x425 mm (HxWxD)

Temperature control (second)Electro-mechanical

Heating elements (second)Lower 1200 W; Upper 1000 W; Grill 1700 W; Large grill 2700 W; Circular 2000 W

Grill type (second)Electric, tilting grill

Soft Close (second)Yes

Second oven temperature range50 °C – 260 °C

Safety thermostat (second)Yes

Heating suspended when door opened (second)Yes

Max power draw10900 W

Current32 A

Voltage220–240 V; 380–415 V (Voltage 2)

Type of electric cableYes, Single phase

Cable testingYes

Additional connection modalitiesYes, Double and Three Phase

Frequency50/60 Hz

Terminal block5 poles

Downloads

Download product documentation, manuals, and specification sheets.

CPF120IGMPBL Spec

PDF

Frequently Asked Questions

What type of hob does the Smeg CPF120IGMPBL have?

This cooker has a mixed hob with six cook zones: three gas burners (2UR dual 4.20 kW, Semi Rapid 1.80 kW, Rapid 3.00 kW), two induction multizone areas (2.10 kW and 1.60 kW with booster functions) and a central Teppanyaki zone rated at 1.40 kW. It features cast iron pan stands and matte black enamelled burner caps.

How do the ovens help with easy cleaning?

The main oven uses a pyrolytic cleaning system, allowing special pyrolytic cycles to automatically clean the interior. The second oven uses Vapor Clean, which employs steam to loosen deposits in the cavity. Both ovens have easy clean enamel interiors and removable inner glass, and the tilting grill in the second oven facilitates cleaning of the roof.

What are the capacities of the two ovens?

The main oven has a net volume of 70 litres and a gross volume of 79 l. The second oven has a net volume of 63 litres and a gross volume of 79 l. Both cavities offer 5 shelf positions and metal racks, providing multiple cooking levels.

What safety features are included?

Safety features include a safety thermostat in both ovens, heating suspended when the door is opened, a tangential cooling system and a cold external door glass to avoid burns. The main oven has a door lock during pyrolysis, and the induction zones provide automatic switch off when overheated, automatic pan detection, minimum pan diameter indication, selected zone indicator and residual heat indicator.

Which energy ratings does this cooker have?

The cooker has two cavities with energy labels. The main cavity has an energy efficiency class of A+, and the second cavity has an energy efficiency class of A. The A+ class helps to save up to 10% energy compared to class A, while guaranteeing maximum performance with minimum consumption according to the provided symbols glossary.

Are there matching alternative colours available?

Alternative Portofino products listed include models CPF120IGMPX (stainless steel), CPF120IGMPWH (white), CPF120IGMPR (red) and CPF120IGMPT (turquoise), offering different colour options with similar styling.
