Smeg KV26N Angled Chimney Hood

The KV26N is a 60 cm angled chimney cooker hood in black glass with a universal aesthetic. It offers ducted or recirculation extraction, perimeter extraction and touch control with back‑lighting. With three speeds plus intensive setting, LED lighting and included charcoal filters, it is designed to efficiently remove grease and cooking odours. Energy efficiency class A and a maximum intensive extraction rate of 666 m³/h provide powerful performance for everyday cooking.

SKU:KV26N

EAN:8017709290610

Category::Cooker Hoods

Quantity:

Key Features

Product family & type: Hood – chimney cooker hood with angled design.

Installation options: Extraction can be ducted out or used in re‑circulation mode.

Perimeter extraction: Perimeter extraction panels are described as very efficient and aid noise reduction.

Controls: Touch control, back‑lighted white, with electronic control and three speeds plus intensive speed.

24 h air filter function: When selected, refreshes the air for about 10 minutes every hour over 24 hours at minimum speed and an imperceptible noise level.

Time‑setting options: Includes a special setting to run after the end of cooking for a pre‑set time and then switch off automatically.

Lighting: Two LED lights, 1.1 W each, with dimmer mode and 4000 K light colour temperature.

Energy efficiency: Annual efficiency consumption 49 kWh/year with energy efficiency class A.

High extraction performance: Free outlet maximum capacity 670 m³/h and intensive extraction rate 666 m³/h.

Quiet operation: Airborne acoustical A‑weighted sound power emission from 44 dBA at minimum speed to 67 dBA at intensive speed.

Grease and odour filtering: Two aluminium anti‑grease filters, charcoal filters included and warning lights to advise when filters need changing.

Lighting efficiency: Lighting efficiency 118.6 lux/W with lighting efficiency class A and average illumination on the cooking surface of 261 lux.

Design and finish: Universal aesthetics in black glass with white serigraphy colour and silk screen logo.

Safety distances: Minimum distance from gas hob 650 mm and from electric hob 450 mm.

Non‑return valve: Equipped with a non‑return valve and 150 mm vent outlet.

Alternative colours available: White and Silver Glass (available colours KV26S – KV26B).

Compatible accessories: Round charcoal filters FLT6, universal charcoal filter KITALLFC and chimney extensions KITCMNKVMB and KITCMNKVX.

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignAngled

AestheticsUniversal

ColourBlack

FinishingGlass

Glass typeBlack

Serigraphy colourWhite

LogoSilk screen

MaterialGlass

EAN code8017709290610

ModelKV26N

Hood width60 cm

Extraction typeDucted out or re‑circulation possible

Electronic controlYes

Perimeter extractionYes

Control settingTouch control back‑lighted White

LED colour (controls)White

Number of speeds3 + Intensive speed

24 h air filter functionYes

Time‑setting optionsYes

Number of lights2

Light typeLED

Light power1.1 W

Dimmer modeYes

Light colour temperature4000 K

Free outlet maximum capacity670 m³/h

Motor power230 W

Number of filters2

Anti‑grease filtersAluminium

Charcoal filters includedYes

Filter replacement indicatorYes (warning light to advise when filters need changing)

Vent outlet150 mm

Minimum distance from gas hob650 mm

Minimum distance from electric hob450 mm

Non return valveYes

Annual efficiency consumption (AEChood)49 kWh/year

Energy efficiency class (EEC)A

Fluid Dynamic Efficiency (FDE)31.5

Fluid Dynamic Efficiency class (FDEC)A

Lighting Efficiency (LE)118.6 lux/W

Lighting Efficiency class (LEC)A

Grease Filtering Efficiency (GFE)77.0 %

Grease Filtering Efficiency class (GFEC)C

Air flow at minimum speed (Qmin)242 m³/h

Maximum extraction rate420 m³/h

Intensive extraction rate666 m³/h

Sound power emission at minimum speed (SPEmin)44 dBA (airbourne acoustical A‑weighted)

Sound power emission at maximum speed (SPEmax)58 dBA (airborne acoustical A‑weighted)

Sound power emission at boost speed (SPEboost)67 dBA (airbourne acoustical A‑weighted)

Time increase factor (F)0.9

Energy Efficiency Index51.1

Measured air flow rate at best efficiency point (Qbep)363 m³/h

Measured air pressure at best efficiency point (Qbep)453 Pa

Measured electric power input at best efficiency point (Wbep)145 W

Normal power of the light system (Wl)2 W

Average illumination on cooking surface (Emiddle)261 lux

Sound power level at highest setting (Lwa)58 dBA

Nominal power232 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1500 mm

Extraction rate IEC 61591 – Speed 1242 m³/h – 44 dBA (Noise level IEC 60704‑2‑13)

Extraction rate IEC 61591 – Speed 2326 m³/h – 51 dBA (Noise level IEC 60704‑2‑13)

Extraction rate IEC 61591 – Speed 3420 m³/h – 58 dBA (Noise level IEC 60704‑2‑13)

Extraction rate IEC 61591 – Intensive speed666 m³/h – 67 dBA (Noise level IEC 60704‑2‑13)

Alternative colours availableWhite, Silver Glass – available colours KV26S – KV26B

Downloads

Download product documentation, manuals, and specification sheets.

KV26N Spec

PDF

Frequently Asked Questions

Can this hood be used in both ducted and recirculation modes?

Yes. Extraction can be ducted out or used in re‑circulation mode. Charcoal filters are included to support operation in recirculation.

What is the minimum installation height above the hob?

The minimum distance from a gas hob is 650 mm and from an electric hob is 450 mm.

How powerful is the extraction on the intensive setting?

The intensive extraction rate is 666 m³/h with an airborne acoustical A‑weighted sound power emission of 67 dBA.

Does the hood warn when filters need changing?

Yes. A warning light advises when filters need changing, and there is a filter replacement indicator.

What is the energy efficiency class of this hood?

The hood has an energy efficiency class A with an annual efficiency consumption of 49 kWh/year.

Are there other colour options available?

Alternative colours available are White and Silver Glass, with available models KV26S and KV26B.
