Smeg KT110PE Victoria Chimney Hood

The SMEG KT110PE is a 110 cm chimney cooker hood in a cream gloss Victoria aesthetic, designed for ducted out or re–circulation extraction. It features painted, brushed steel construction with steel effect Victoria control knobs and LED lighting at 3000 K. With three speeds plus intensive setting, aluminium anti–grease filters and A energy efficiency class, it offers powerful extraction performance for use above gas or electric hobs within the stated installation distances.

SKU:KT110PE

EAN:8017709211707

Category::Cooker Hoods

Quantity:

Key Features

Product family & type: Hood – Chimney Cooker Hoods with chimney design.

Width: 110 cm hood width for larger cooking areas.

Extraction options: Ducted out or re–circulation possible for flexible installation.

Aesthetics: Victoria design in cream colour with gloss finishing and applied logo.

Controls: Victoria control knobs, steel effect, with 2 controls and 3 speeds plus intensive speed.

Lighting: 2 LED lights, 1 W each, 3000 K colour temperature scale.

Filters: 4 aluminium anti–grease filters with non return valve.

Maximum free outlet capacity: 820 m³/h.

Extraction rate (IEC 61591): up to 554 m³/h at speed 3 and 784 m³/h at intensive speed.

Noise levels (IEC 60704–2–13): 49 dBA at speed 1, 57 dBA at speed 2, 63 dBA at speed 3 and 71 dBA at intensive speed.

Energy performance: Annual efficiency consumption 57 kWh/year with energy efficiency class A.

Fluid Dynamic Efficiency: 31,1 with class A.

Lighting efficiency: 83,2 lux/W with lighting efficiency class A.

Grease filtering efficiency: 69,2 % with grease filtering efficiency class D.

Vent outlet: 150 mm vent outlet for extraction.

Minimum installation distances: 750 mm from gas hob and 650 mm from electric hob.

Motor and power: Motor power 275 W, nominal power 278 W.

Electrical connection: Voltage 220–240 V, frequency 50–60 Hz, power supply cable length 1000 mm.

Alternative colours available: White, Black, Stainless steel.

Compatible accessories: FLT6 round charcoal filters (kit 2 pieces) and KITALLFC universal charcoal filter Stainless Steel AISI 304.

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

ExtractionDucted out or re–circulation possible

MaterialPainted material

Type of steelBrushed

EAN code8017709211707

ModelKT110PE

Hood width110 cm

AestheticsVictoria

ColourCream

FinishingGloss

LogoApplied

Control settingControl knobs

No. of controls2

Control knobsVictoria

Controls colourSteel effect

No. of speeds3 + intensive speed

No. of lights2

Light typeLED

Light power1 W

Light colour temperature3000 K

Free outlet maximum capacity820 m³/h

Motor power275 W

No. of filters4

Anti–grease filtersAluminium

Vent outlet150 mm

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Non return valveYes

Annual efficiency consumption (AEChood)57 kWh/year

Energy efficiency class (EEC)A

Fluid Dynamic Efficiency (FDE)31,1

Fluid Dynamic Efficiency class (FDEC)A

Lighting Efficiency (LE)83,2 lux/W

Lighting Efficiency Class (LEC)A

Grease Filtering Efficiency (GFE)69,2 %

Grease Filtering Efficiency Class (GFEC)D

Air flow at minimum speed (Qmin)326 m³/h

Maximum extraction rate554 m³/h

Intensive extraction rate784 m³/h

Extraction rate IEC 61591 – speed 1326 m³/h

Noise level IEC 60704–2–13 – speed 149 dBA

Extraction rate IEC 61591 – speed 2439 m³/h

Noise level IEC 60704–2–13 – speed 257 dBA

Extraction rate IEC 61591 – speed 3554 m³/h

Noise level IEC 60704–2–13 – speed 363 dBA

Extraction rate IEC 61591 – intensive speed784 m³/h

Noise level IEC 60704–2–13 – intensive speed71 dBA

Airbourne acoustical A–weighted sound power emission at minimum speed (SPEmin)49 dBA

Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)63 dBA

Airbourne acoustical A–weighted sound power emission at boost speed (SPEboost)71 dBA

Energy Efficiency Index per first cavity52,2

Measured air flow rate at best efficiency point (Qbep)413 m³/h

Measured air pressure at best efficiency point (Qbep)456 Pa

Measured electric power input at best efficiency point (Wbep)168 W

Normal power of the light system (Wl)2 W

Average illumination of the light on the cooking surface (Emiddle)183 lux

Sound power level at highest setting (Lwa)63 dBA

Nominal power278 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1000 mm

Alternative colours availableWhite, Black, Stainless steel

Available colours modelsKT110BE – KT110BLE – KTR110XE

Downloads

Download product documentation, manuals, and specification sheets.

KT110PE - Bulletin.pdf

PDF

KT110PE Spec

PDF

Frequently Asked Questions

What extraction options does the KT110PE support?

Extraction can be ducted out or re–circulation is possible, providing flexibility depending on the kitchen layout and installation requirements.

How many speeds and what intensive function are available?

The hood has 3 speeds plus an intensive speed. The intensive or turbo setting is intended for situations when extra fast extraction is required.

What are the minimum installation distances from the hob?

The minimum distance is 750 mm from a gas hob and 650 mm from an electric hob.

What accessories are compatible with this hood?

Compatible accessories include FLT6 round charcoal filters (kit 2 pieces) and the KITALLFC universal charcoal filter in Stainless Steel AISI 304.

How can the KITALLFC charcoal filter be cleaned and dried?

The KITALLFC filter can be washed in a dishwasher at 50 °C using water and suitable detergent. To dry it, it can be put in the oven at 180 °C for 25 minutes.

What is the energy efficiency class and annual consumption?

The hood has an energy efficiency class A and an annual efficiency consumption (AEChood) of 57 kWh/year.
