Smeg KSED95XE Chimney Hood

The SMEG KSED95XE is a 90 cm universal-style chimney cooker hood in brushed stainless steel, designed for ducted out or re-circulating extraction. It offers three speeds controlled by a slider, with a maximum free outlet capacity of 595 m³/h and LED lighting at 4000 K to illuminate the cooking area. Aluminium anti-grease filters and a non return valve support effective extraction above gas or electric hobs at the specified safety distances.

SKU:KSED95XE

EAN:8017709206109

Category::Cooker Hoods

Quantity:

Key Features

Product family & type: Hood, chimney cooker hood with chimney design aesthetics.

Installation options: Extraction can be ducted out or re-circulation is possible.

Width: 90 cm hood width for larger cooking areas.

Material and finish: Stainless steel, brushed type of steel with embossed logo.

Aesthetics: Universal style in stainless steel colour with brushed finishing.

Controls: Slider control setting with 3 speeds for extraction.

Lighting: 2 LED lights, 1 W each, 4000 K light colour temperature scale for cooking surface illumination.

Maximum free outlet capacity: Up to 595 m³/h extraction capacity.

Motor power: 200 W motor with nominal power of 202 W.

Filters: 3 aluminium anti-grease filters; model has filters to help remove grease from steam during cooking.

Vent outlet: 150 mm vent outlet with non return valve.

Minimum distances: 750 mm from gas hob and 650 mm from electric hob.

Energy efficiency class: Rated B with 54 kWh/year annual efficiency consumption (AEChood).

Lighting efficiency: 74,3 lux/W, lighting efficiency class A.

Grease filtering efficiency: 70,8 % with grease filtering efficiency class D.

Noise levels: From 50 dBA at minimum speed to 65 dBA at maximum speed (IEC 60704-2-13).

Alternative colours available: Black, Anthracite, Cream, Red Wine (models KSED95NEE, KSED95AE, KSED95PE, KSED95RWE).

Lights feature: Cooker hood lights to illuminate the cooking area or add to kitchen ambience.

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

ExtractionDucted out or re-circulation possible

MaterialStainless steel, brushed type of steel

EAN code8017709206109

Hood width90 cm

AestheticsUniversal

Colour / finishingStainless steel, brushed; logo embossed

Control settingSlider

Number of speeds3

Number of lights2

Light typeLED

Light power1 W

Light colour temperature4000 K

Free outlet maximum capacity595 m³/h

Motor power200 W

Number of filters3 aluminium anti-grease filters

Vent outlet150 mm

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Non return valveYes

Extraction rate IEC 61591 – speed 1328 m³/h, 50 dBA

Extraction rate IEC 61591 – speed 2420 m³/h, 57 dBA

Extraction rate IEC 61591 – speed 3588 m³/h, 65 dBA

Annual efficiency consumption (AEChood)54 kWh/year

Energy efficiency class (EEC)B

Fluid Dynamic Efficiency (FDE)25,3

Fluid Dynamic Efficiency class (FDEC)B

Lighting efficiency (LE)74,3 lux/W

Lighting efficiency class (LEC)A

Grease filtering efficiency (GFE)70,8 %

Grease filtering efficiency class (GFEC)D

Air flow at minimum speed (Qmin)328 m³/h

Maximum extraction rate588 m³/h

Airborne acoustical A-weighted sound power emission at minimum speed (SPEmin)50 dBA

Airborne acoustical A-weighted sound power emission at maximum speed (SPEmax)65 dBA

Time increase factor (F)1,1

Energy Efficiency Index per first cavity61,2

Measured air flow rate at best efficiency point (Qbep)318 m³/h

Measured air pressure at best efficiency point (Qbep)375 Pa

Measured electric power input at best efficiency point (Wbep)131 W

Normal power of the light system (Wl)2 W

Average illumination on cooking surface (Emiddle)164 lux

Sound power level at highest setting (Lwa)65 dBA

Nominal power202 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1000 mm

Downloads

Download product documentation, manuals, and specification sheets.

KSED95XE - Bulletin.pdf

PDF

KSED95XE Spec

PDF

Frequently Asked Questions

What type of cooker hood is the KSED95XE?

It is a chimney cooker hood with a chimney design, belonging to the Hood product family and featuring universal aesthetics.

Can this hood be used for both ducted and recirculating extraction?

Yes. Extraction can be ducted out or re-circulation is possible, giving flexibility for different kitchen installations.

What are the minimum installation heights above the hob?

The minimum distance from a gas hob is 750 mm and from an electric hob is 650 mm.

How many speeds and what maximum extraction rate does it offer?

The hood has 3 speeds. The maximum extraction rate is 588 m³/h, with a free outlet maximum capacity of 595 m³/h.

What are the energy and lighting efficiency classes?

The hood has an energy efficiency class B with an annual efficiency consumption of 54 kWh/year, and a lighting efficiency class A with 74,3 lux/W.

Which accessories are compatible with this model?

Compatible accessories include FLT6 round charcoal filters (kit 2 pieces) and the KITALLFC universal charcoal filter in Stainless Steel AISI 304, which can be washed in the dishwasher at 50 °C and dried in the oven at 180 °C for 25 minutes.
