Smeg KSED95NEE Chimney Hood

The SMEG KSED95NEE is a 90 cm Victoria chimney cooker hood in black, designed for ducted extraction or re-circulation. It features slider controls with 3 speeds, a maximum free outlet capacity of 595 m³/h and LED lighting with a 4000 K colour temperature. Aluminium anti-grease filters help remove grease from cooking steam, while the hood delivers B-class energy efficiency with an annual energy consumption of 54 kWh/year.

SKU:KSED95NEE

EAN:8017709235062

Category::Cooker Hoods

Quantity:

Key Features

Product family and type: Chimney cooker hood from the Victoria aesthetics range.

Hood width: 90 cm black painted material with brushed steel.

Extraction options: Ducted out or re-circulation possible with non return valve.

Controls: Slider control setting with 3 speeds.

Lighting: 2 LED lights, 1 W each, 4000 K colour temperature scale.

Maximum extraction performance: Free outlet maximum capacity 595 m³/h; maximum extraction rate 588 m³/h.

Energy efficiency: Energy efficiency class B with 54 kWh/year Annual Efficiency Consumption (AEChood).

Grease filtration: 3 aluminium anti-grease filters with 70,8 % Grease Filtering Efficiency (GFEC class D).

Lighting efficiency: Lighting Efficiency 74,3 lux/W (Lighting Efficiency Class A).

Noise levels: From 50 dBA at minimum speed to 65 dBA at maximum speed.

Vent outlet: 150 mm vent outlet for connection to ducting.

Minimum installation distances: 750 mm from gas hob, 650 mm from electric hob.

Electrical connection: Nominal power 202 W, 220–240 V, 50–60 Hz, power supply cable length 1000 mm.

Alternative colours available: Stainless steel, Anthracite and Red Wine (models KSED95XE, KSED95AE, KSED95RWE).

Filters and lights: Model has filters to help remove grease from cooking steam and lights to illuminate the cooking area or add ambience.

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

ExtractionDucted out or re-circulation possible

MaterialPainted material

Type of steelBrushed

EAN code8017709235062

Hood width90 cm

AestheticsVictoria

ColourBlack

LogoSilk screen

Control settingSlider

No. of speeds3

No. of lights2

Light typeLED

Light power1 W

Light colour temperature4000 K

Free outlet maximum capacity595 m³/h

Motor power200 W

No. of filters3

Anti-grease filtersAluminium

Vent outlet150 mm

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Non return valveYes

Extraction rate IEC 61591 – Speed 1328 m³/h

Noise level IEC 60704-2-13 – Speed 150 dBA

Extraction rate IEC 61591 – Speed 2420 m³/h

Noise level IEC 60704-2-13 – Speed 257 dBA

Extraction rate IEC 61591 – Speed 3588 m³/h

Noise level IEC 60704-2-13 – Speed 365 dBA

Annual Efficiency Consumption (AEChood)54 kWh/year

Energy efficiency class (EEC)B

Fluid Dynamic Efficiency (FDE)25,3

Fluid Dynamic Efficiency class (FDEC)B

Lighting Efficiency (LE)74,3 lux/W

Lighting Efficiency Class (LEC)A

Grease Filtering Efficiency (GFE)70,8 %

Grease Filtering Efficiency Class (GFEC)D

Air flow at minimum speed (Qmin)328 m³/h

Maximum extraction rate588 m³/h

Airborne acoustical A–weighted sound power emission at minimum speed (SPEmin)50 dBA

Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)65 dBA

Time increase factor (F)1,1

Energy Efficiency Index per first cavity61,2

Measured air flow rate at best efficiency point (Qbep)318 m³/h

Measured air pressure at best efficiency point (Qbep)375 Pa

Measured electric power input at best efficiency point (Wbep)131 W

Normal power of the light system (Wl)2 W

Average illumination of the light on the cooking surface (Emiddle)164 lux

Sound power level at highest setting (Lwa)65 dBA

Nominal power202 W

Voltage220–240 V

Frequency (Hz)50–60 Hz

Power supply cable length1000 mm

Downloads

Download product documentation, manuals, and specification sheets.

KSED95NEE Spec

PDF

Frequently Asked Questions

What type of cooker hood is the SMEG KSED95NEE?

It is a chimney cooker hood with a 90 cm width, part of the Victoria aesthetics range, designed in black painted material with brushed steel.

Can this hood be used in both ducted and re-circulation modes?

Yes. The extraction system allows for ducted out or re-circulation operation and includes a non return valve.

What are the extraction rates and noise levels at different speeds?

At speed 1 the extraction rate is 328 m³/h with 50 dBA noise. At speed 2 it is 420 m³/h with 57 dBA noise. At speed 3 it reaches 588 m³/h with 65 dBA noise.

What is the energy efficiency class and annual consumption?

The energy efficiency class is B, with an Annual Efficiency Consumption (AEChood) of 54 kWh/year.

How far above the hob should the hood be installed?

The minimum distance is 750 mm from a gas hob and 650 mm from an electric hob.

Which charcoal filters are compatible?

Compatible accessories include FLT6 round charcoal filters (kit 2 pieces) and KITALLFC universal charcoal filter in Stainless Steel AISI 304, which can be washed in a dishwasher at 50 °C and dried in an oven at 180 °C for 25 minutes.
