Smeg KSED65XE Chimney Hood

The SMEG KSED65XE is a 60 cm stainless steel chimney cooker hood designed for ducted or re-circulation extraction. With a universal aesthetic and brushed finish, it features slider controls with 3 speeds, efficient LED lighting and aluminium anti-grease filters. Offering a maximum extraction rate of 635 m³/h and B energy efficiency, it is suited to users seeking effective steam and grease removal with clear illumination of the cooking area.

SKU:KSED65XE

EAN:8017709206079

Category::Cooker Hoods

Quantity:

Key Features

60 cm chimney cooker hood in brushed stainless steel with universal aesthetics.

Ducted out or re-circulation extraction possible for flexible installation.

Slider controls with 3 speeds to adjust extraction performance.

Maximum extraction rate 635 m³/h with free outlet maximum capacity 600 m³/h.

LED lighting with 2 lights, 1 W each, 4000 K colour temperature for cooking area illumination.

Aluminium anti-grease filters to help remove grease from steam during cooking.

Energy efficiency class B with annual consumption of 60 kWh/year.

Lighting Efficiency Class A with lighting efficiency of 100,2 lux/W.

Noise levels from 53 to 67 dBA depending on selected speed.

Non return valve included and 150 mm vent outlet.

Minimum installation distances of 750 mm from gas hobs and 650 mm from electric hobs.

Alternative colour options available in White (KSED65BE), Black (KSED65NE) and Cream (KSED65PE).

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

AestheticsUniversal

ColourStainless steel

FinishingBrushed

Material / type of steelStainless steel, brushed

LogoEmbossed

ModelKSED65XE

EAN code8017709206079

Hood width60 cm

ControlsSlider

Number of speeds3

Number of lights2

Light typeLED

Light power1 W

Light colour temperature4000 K

Normal power of the light system (Wl)2 W

Average illumination on cooking surface (Emiddle)221 lux

ExtractionDucted out or re-circulation possible

Free outlet maximum capacity600 m³/h

Air flow at minimum speed (Qmin)351 m³/h

Maximum extraction rate635 m³/h

Extraction rate IEC 61591 – speed 1351 m³/h

Extraction rate IEC 61591 – speed 2420 m³/h

Extraction rate IEC 61591 – speed 3635 m³/h

Noise level IEC 60704-2-13 – speed 153 dBA

Noise level IEC 60704-2-13 – speed 257 dBA

Noise level IEC 60704-2-13 – speed 367 dBA

Airborne acoustical A–weighted sound power emission at minimum speed (SPEmin)53 dBA

Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)67 dBA

Sound power level at highest setting (Lwa)67 dBA

Motor power200 W

Measured air flow rate at best efficiency point (Qbep)355 m³/h

Measured air pressure at best efficiency point (Qbep)385 Pa

Measured electric power input at best efficiency point (Wbep)146 W

Number of filters2

Anti-grease filtersAluminium

Vent outlet150 mm

Non return valveYes

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Annual efficiency consumption (AEChood)60 kWh/year

Energy efficiency class (EEC)B

Fluid Dynamic Efficiency (FDE)26

Fluid Dynamic Efficiency class (FDEC)B

Lighting Efficiency (LE)100,2 lux/W

Lighting Efficiency Class (LEC)A

Grease Filtering Efficiency (GFE)74,4 %

Grease Filtering Efficiency Class (GFEC)D

Time increase factor (F)1,1

Energy Efficiency Index per first cavity62,2

Nominal power202 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1000 mm

Alternative colours availableWhite, Black, Cream

Available colour modelsKSED65BE – KSED65NE – KSED65PE

Downloads

Download product documentation, manuals, and specification sheets.

KSED65XE - Bulletin.pdf

PDF

KSED65XE Spec

PDF

Frequently Asked Questions

Can this hood be used with both ducted and recirculation setups?

Yes. Extraction can be ducted out or operated in re-circulation mode. The hood has a 150 mm vent outlet and is compatible with charcoal filter accessories such as FLT6 and KITALLFC for recirculation use.

What are the minimum installation heights above the hob?

The minimum distance from a gas hob is 750 mm, and the minimum distance from an electric hob is 650 mm.

How many speeds and what extraction rates does it offer?

The hood has 3 speeds controlled by a slider. Extraction rates are 351 m³/h at speed 1, 420 m³/h at speed 2 and 635 m³/h at speed 3 (IEC 61591).

How loud is the SMEG KSED65XE during operation?

Noise levels are 53 dBA at speed 1, 57 dBA at speed 2 and 67 dBA at speed 3 according to IEC 60704-2-13. The airborne acoustical A–weighted sound power emission ranges from 53 dBA at minimum speed to 67 dBA at maximum speed.

What is the energy efficiency rating of this hood?

The hood has an energy efficiency class B with an annual efficiency consumption of 60 kWh/year. Lighting Efficiency Class is A, and Fluid Dynamic Efficiency Class is B.

What lighting does the hood use?

It uses 2 LED lights rated at 1 W each, with a colour temperature of 4000 K. The normal power of the light system is 2 W, providing an average illumination of 221 lux on the cooking surface.
