Smeg KSED65NEE Chimney Hood

Smeg KSED65NEE Chimney Hood

The SMEG KSED65NEE is a 60 cm Victoria-style chimney cooker hood in black, designed for ducted out or recirculation extraction. With three speeds, a maximum extraction rate of 635 m³/h and aluminium anti-grease filters, it helps remove grease from steam during cooking. LED lighting with a 4000 K colour temperature provides illumination of the cooking surface. The hood features slider controls and is suitable for installation above gas and electric hobs within the stated distances.

SKU:KSED65NEE
EAN:8017709212063
Category::Cooker Hoods
2 Year Warranty

Key Features

Chimney cooker hood design with 60 cm hood width and Victoria aesthetics.
Black painted material with brushed steel and silk screen logo.
Ducted out or re-circulation extraction possible via 150 mm vent outlet.
Slider control setting with 3 speeds for flexible extraction performance.
High extraction capacity with maximum extraction rate of 635 m³/h.
LED lighting with 2 lights, 1 W each, 4000 K colour temperature.
Aluminium anti-grease filters to help remove grease from steam during cooking.
Annual energy consumption of 60 kWh/year and energy efficiency class B.
Lighting efficiency class A with lighting efficiency of 100,2 lux/W.
Grease filtering efficiency of 74,4 % with class D.
Non return valve included.
Minimum distance from GAS hob of 750 mm and from ELECTRIC hob of 650 mm.
Alternative colours available : White, Stainless steel, Cream.
Compatible charcoal filter accessories FLT6 and KITALLFC.

Technical Spec

Product familyHood
Hood typeChimney Cooker Hoods
DesignChimney
ExtractionDucted out or re-circulation possible
MaterialPainted material
Type of steelBrushed
EAN code8017709212063
ModelKSED65NEE
Hood width60 cm
AestheticsVictoria
ColourBlack
LogoSilk screen
Control settingSlider
Number of speeds3
Number of lights2
Light typeLED
Light power1 W
Light colour temperature4000 K
Free outlet maximum capacity600 m³/h
Motor power200 W
Number of filters2
Anti-grease filtersAluminium
Vent outlet150 mm
Minimum distance from GAS hob750 mm
Minimum distance from ELECTRIC hob650 mm
Non return valveYes
Extraction rate IEC 61591 – Speed 1351 m³/h
Noise level IEC 60704-2-13 – Speed 153 dBA
Extraction rate IEC 61591 – Speed 2420 m³/h
Noise level IEC 60704-2-13 – Speed 257 dBA
Extraction rate IEC 61591 – Speed 3635 m³/h
Noise level IEC 60704-2-13 – Speed 367 dBA
Annual efficiency consumption (AEChood)60 kWh/year
Energy efficiency class (EEC)B
Fluid Dynamic Efficiency (FDE)26
Fluid Dynamic Efficiency class (FDEC)B
Lighting Efficiency (LE)100,2 lux/W
Lighting Efficiency Class (LEC)A
Grease Filtering Efficiency (GFE)74,4 %
Grease Filtering Efficiency Class (GFEC)D
Air flow at minimum speed (Qmin)351 m³/h
Maximum extraction rate635 m³/h
Airborne acoustical A-weighted sound power emission at minimum speed (SPEmin)53 dBA
Airborne acoustical A-weighted sound power emission at maximum speed (SPEmax)67 dBA
Time increase factor (F)1,1
Energy Efficiency Index per first cavity62,2
Measured air flow rate at best efficiency point (Qbep)355 m³/h
Measured air pressure at best efficiency point (Qbep)385 Pa
Measured electric power input at best efficiency point (Wbep)146 W
Normal power of the light system (Wl)2 W
Average illumination of the light on the cooking surface (Emiddle)221 lux
Sound power level at highest setting (Lwa)67 dBA
Nominal power202 W
Voltage220–240 V
Frequency50–60 Hz
Power supply cable length1000 mm
Alternative colours availableWhite, Stainless steel, Cream

Downloads

Download product documentation, manuals, and specification sheets.

KSED65NEE Spec

PDF

Frequently Asked Questions

What is the maximum extraction rate of the SMEG KSED65NEE?

The maximum extraction rate is 635 m³/h at speed 3.

Can this cooker hood be used in recirculation mode?

Yes. Extraction is ducted out or re-circulation is possible, and compatible charcoal filters such as FLT6 and KITALLFC are available.

What type of filters are supplied with the hood?

The hood has 2 aluminium anti-grease filters. These help remove grease from the steam emanating from pans during cooking.

What lighting does the hood provide?

It features 2 LED lights with a power of 1 W each, a colour temperature of 4000 K and an average illumination on the cooking surface of 221 lux.

What are the minimum installation heights above hobs?

The minimum distance from a gas hob is 750 mm and from an electric hob is 650 mm.

What is the energy efficiency class of the KSED65NEE?

The energy efficiency class (EEC) is B, with an annual energy consumption of 60 kWh/year.
