Smeg KSED65BE Chimney Hood

The SMEG KSED65BE is a 60 cm white Victoria-style chimney cooker hood designed for use with either ducted extraction or recirculation. It offers three slider-controlled speeds with a maximum extraction rate of 635 m³/h and aluminium anti-grease filters. Two 2 W LED lights with 4000 K colour temperature illuminate the cooking area. With an energy efficiency class B and a non return valve, this hood is suitable for gas and electric hobs within the stated clearances.

SKU:KSED65BE

EAN:8017709212070

Category::Cooker Hoods

Quantity:

Key Features

60 cm chimney cooker hood from the Victoria aesthetic range.

White painted material with brushed steel and silk screen logo.

Ducted out or recirculation operation for flexible installation.

Three slider-controlled speeds to adjust extraction as needed.

Maximum extraction rate 635 m³/h for powerful ventilation.

Free outlet maximum capacity 600 m³/h with 200 W motor power.

LED lighting 2 × 2 W with 4000 K colour temperature to illuminate the cooking surface.

Aluminium anti-grease filters with two filters fitted as standard.

Grease Filtering Efficiency 74,4 % (Grease Filtering Efficiency Class D).

Lighting Efficiency 100,2 lux/W with Lighting Efficiency Class A.

Energy efficiency class B with annual efficiency consumption of 60 kWh/year.

Non return valve included to help prevent backflow through the vent outlet.

Vent outlet 150 mm for connection to extraction ducting.

Minimum distance from gas hob 750 mm and from electric hob 650 mm.

Sound power level at highest setting 67 dBA with 53 dBA at minimum speed.

Nominal power 202 W with 220–240 V, 50–60 Hz electrical connection.

Compatible charcoal filter accessories available for recirculation use.

Alternative colours available: Black, Stainless steel, Cream.

Model has filters to help remove grease from steam during cooking.

Integrated lights to illuminate the cooking area or add to kitchen ambience.

Technical Spec

ModelKSED65BE

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

AestheticsVictoria

ColourWhite

MaterialPainted material

Type of steelBrushed

LogoSilk screen

EAN code8017709212070

Hood width60 cm

ExtractionDucted out or re-circulation possible

Control settingSlider

Number of speeds3

Number of lights2

Light typeLED

Light power2 W

Light colour temperature4000 K

Free outlet maximum capacity600 m³/h

Motor power200 W

Number of filters2

Anti-grease filtersAluminium

Vent outlet150 mm

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Non return valveYes

Annual efficiency consumption (AEChood)60 kWh/year

Energy efficiency class (EEC)B

Fluid Dynamic Efficiency (FDE)26

Fluid Dynamic Efficiency class (FDEC)B

Lighting Efficiency (LE)100,2 lux/W

Lighting Efficiency Class (LEC)A

Grease Filtering Efficiency (GFE)74,4 %

Grease Filtering Efficiency Class (GFEC)D

Air flow at minimum speed (Qmin)351 m³/h

Maximum extraction rate635 m³/h

Time increase factor (F)1,1

Energy Efficiency Index per first cavity62,2

Measured air flow rate at best efficiency point (Qbep)355 m³/h

Measured air pressure at best efficiency point (Qbep)385 Pa

Measured electric power input at best efficiency point (Wbep)146 W

Normal power of the light system (Wl)2 W

Average illumination on cooking surface (Emiddle)221 lux

Extraction rate IEC 61591 speed 1351 m³/h

Noise level IEC 60704-2-13 speed 153 dBA

Extraction rate IEC 61591 speed 2420 m³/h

Noise level IEC 60704-2-13 speed 257 dBA

Extraction rate IEC 61591 speed 3635 m³/h

Noise level IEC 60704-2-13 speed 367 dBA

Airborne acoustical A-weighted sound power emission at minimum speed (SPEmin)53 dBA

Airborne acoustical A-weighted sound power emission at maximum speed (SPEmax)67 dBA

Sound power level at highest setting (Lwa)67 dBA

Nominal power202 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1000 mm

Alternative colours availableBlack, Stainless steel, Cream

Downloads

Download product documentation, manuals, and specification sheets.

KSED65BE Spec

PDF

Frequently Asked Questions

Can this hood be used for both ducted extraction and recirculation?

Yes. The extraction type allows for ducted out or re-circulation operation, so it can be configured either to vent air outside or to recirculate air through suitable filters.

What is the maximum extraction rate of the SMEG KSED65BE?

The maximum extraction rate is 635 m³/h. At minimum speed the airflow is 351 m³/h, and at speed 2 it is 420 m³/h.

How noisy is the hood during operation?

At minimum speed the airborne acoustical A-weighted sound power emission is 53 dBA, and at maximum speed it is 67 dBA. The sound power level at the highest setting (Lwa) is also 67 dBA.

What clearances are required above the hob?

The minimum distance from a gas hob is 750 mm and from an electric hob 650 mm.

Which filters and accessories are compatible with this hood?

The hood is supplied with two aluminium anti-grease filters. Compatible accessories include the FLT6 round charcoal filters (kit 2 pieces) and the KITALLFC universal charcoal filter in Stainless Steel AISI 304, which can be washed in a dishwasher at 50 °C and dried in an oven at 180 °C for 25 minutes.

What is the energy efficiency class and annual energy consumption?

The energy efficiency class (EEC) is B, and the annual efficiency consumption (AEChood) is 60 kWh/year.
