Smeg KS110XE Symphony Chimney Hood

The SMEG KS110XE is a 110 cm T flat chimney cooker hood in brushed stainless steel with a universal aesthetic and embossed logo. Designed for ducted out or re-circulation installation, it offers three speeds plus intensive extraction, LED lighting at 4000 K and electronic button controls. With a free outlet maximum capacity of 800 m³/h, aluminium anti-grease filters and a filter replacement indicator, it is intended for effective kitchen extraction and illumination.

SKU:KS110XE

EAN:8017709201869

Category::Cooker Hoods

Quantity:

Key Features

Chimney cooker hood, T flat design: Universal aesthetic in brushed stainless steel with embossed logo.

Wide 110 cm hood width: Suitable for larger cooking areas (minimum 750 mm from gas hobs, 650 mm from electric hobs).

Ducted out or re-circulation operation: Flexible extraction with 150 mm vent outlet and non return valve.

Electronic button controls: Simple control setting with three speeds plus intensive speed.

High extraction performance: Free outlet maximum capacity 800 m³/h; intensive extraction rate 702 m³/h.

LED lighting 4000 K: Two 1 W LED lights provide an average 370 lux on the cooking surface.

Aluminium anti-grease filters: Three filters with a grease filtering efficiency of 78,7 % (Class C).

Filter replacement indicator: Warning light(s) advise when filters need changing.

Intensive/turbo setting: Extra fast extraction when required, with airborne acoustical A–weighted sound power emission at boost speed 72 dBA.

Automatic switch-off function: Time-setting options allow the hood to run after cooking for a pre-set time then switch off automatically.

Energy efficiency class B: Annual efficiency consumption 62 kWh/year with fluid dynamic efficiency class B.

Lighting efficiency class A: Lighting efficiency 84,1 lux/W with normal light system power 2 W.

Multiple colour options: Stainless steel as KS110XE, with alternative black KS110BLE and cream KS110PE models available.

Compatible charcoal filters: Optional FLT4 charcoal filter and KITALLFC universal charcoal filter available.

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

ModelKS110XE

DesignT flat

AestheticsUniversal

Colour / finishingStainless steel, brushed; embossed logo

Material / type of steelStainless steel, brushed

EAN code8017709201869

Hood width110 cm

Extraction typeDucted out or re-circulation possible

Control settingElectronic buttons

No. of speeds3 + intensive speed

Time-setting optionsYes (switch off automatically after pre-set time)

No. of lights2

Light typeLED

Light power1 W (each), normal power of light system (Wl) 2 W

Light colour temperature4000 K

Free outlet maximum capacity800 m³/h

Maximum extraction rate513 m³/h

Intensive extraction rate702 m³/h

Air flow at minimum speed (Qmin)295 m³/h

Motor power275 W

No. of filters3

Anti-grease filtersAluminium

Filter replacement indicatorYes

Vent outlet150 mm

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Non return valveYes

Extraction rate IEC 61591 – Speed 1295 m³/h – 51 dBA (IEC 60704-2-13)

Extraction rate IEC 61591 – Speed 2395 m³/h – 58 dBA

Extraction rate IEC 61591 – Speed 3513 m³/h – 64 dBA

Extraction rate IEC 61591 – Intensive702 m³/h – 72 dBA

Annual efficiency consumption (AEChood)62 kWh/year

Energy efficiency class (EEC)B

Fluid Dynamic Efficiency (FDE)27,9

Fluid Dynamic Efficiency class (FDEC)B

Lighting Efficiency (LE)84,1 lux/W

Lighting Efficiency Class (LEC)A

Grease Filtering Efficiency (GFE)78,7 %

Grease Filtering Efficiency Class (GFEC)C

Airborne acoustical A–weighted sound power emission at minimum speed (SPEmin)51 dBA

Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)64 dBA

Airborne acoustical A–weighted sound power emission at boost speed (SPEboost)72 dBA

Time increase factor (F)1,00

Measured air flow rate at best efficiency point (Qbep)373 m³/h

Measured air pressure at best efficiency point (Qbep)430 Pa

Measured electric power input at best efficiency point (Wbep)160 W

Average illumination on cooking surface (Emiddle)370 lux

Sound power level at highest setting (Lwa)64 dBA

Nominal power278 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1000 mm

Alternative colours availableBlack, Cream – Available as KS110BLE, KS110PE

Downloads

Download product documentation, manuals, and specification sheets.

KS110XE - Bulletin.pdf

PDF

KS110XE Spec

PDF

Frequently Asked Questions

What are the extraction rates of the SMEG KS110XE?

The air flow at minimum speed is 295 m³/h, with a maximum extraction rate of 513 m³/h and an intensive extraction rate of 702 m³/h. The free outlet maximum capacity is 800 m³/h.

How noisy is this cooker hood during operation?

At minimum speed, the airborne acoustical A–weighted sound power emission is 51 dBA. At maximum speed it is 64 dBA, and at boost (intensive) speed it is 72 dBA.

What is the energy efficiency class of the KS110XE?

The cooker hood has an energy efficiency class B with an annual efficiency consumption of 62 kWh/year. The fluid dynamic efficiency class is B and the lighting efficiency class is A.

Which filters does this hood use?

It is equipped with three aluminium anti-grease filters and can also use optional charcoal filters FLT4 and KITALLFC. A filter replacement indicator warns when filters need changing.

Can the KS110XE be used in re-circulation mode?

Yes. The extraction system allows for ducted out or re-circulation operation. Charcoal filters such as FLT4 or KITALLFC can be used for re-circulation configurations.

What colour options are available for this model?

The KS110XE is in brushed stainless steel. Alternative colours available are black (KS110BLE) and cream (KS110PE).
