Smeg KPF9X Portofino Chimney Hood

The SMEG KPF9X is a 90 cm stainless steel chimney cooker hood from the Portofino range, designed for ducted or recirculation extraction. It offers three speeds plus an intensive setting, with a maximum extraction rate of 630 m³/h and an intensive extraction rate of 781 m³/h. Featuring A+ energy efficiency, stainless steel anti-grease filters and 4000 K LED lighting, it is suitable for use above gas or electric hobs within the stated minimum distances.

SKU:KPF9X

EAN:8017709236373

Category::Cooker Hoods

Quantity:

Key Features

Product family & type: Hood – Chimney cooker hood design with Portofino aesthetics.

Extraction options: Ducted out or re–circulation operation possible.

Hood width: 90 cm stainless steel body with brushed finishing and applied logo.

Energy efficiency: A+ energy efficiency class with Annual Efficiency Consumption of 40 kWh/year.

Powerful extraction: Free outlet maximum capacity 815 m³/h; maximum extraction rate 630 m³/h; intensive extraction rate 781 m³/h.

Multiple speeds: 3 speeds plus intensive/turbo setting for extra fast extraction.

LED lighting: 2 × 2 W LED lights, 4000 K, Lighting Efficiency 78,2 lux/W (Class A), average illumination 172 lux.

Grease filtering: 3 stainless steel anti-grease filters, Grease Filtering Efficiency 78,5 % (Class C).

Quiet operation: 48 dBA at minimum speed, 67 dBA at maximum speed, 72 dBA at intensive speed.

Efficient airflow: Fluid Dynamic Efficiency 36,2 (Class A); air flow at minimum speed 288 m³/h.

Controls: Portofino style control knobs, 2 controls with steel effect finish.

Vent outlet: 150 mm vent outlet with non return valve.

Hob clearance: Minimum distance from gas hob 750 mm; minimum distance from electric hob 650 mm.

Electrical connection: Nominal power 277 W; motor power 275 W; 220–240 V; 50–60 Hz; 1000 mm power supply cable.

Available colours: Stainless steel plus White, Black, Anthracite, Yellow, Green, Red and Orange (various model codes).

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

AestheticsPortofino

ModelKPF9X

EAN code8017709236373

Hood width90 cm

MaterialStainless steel, brushed type of steel

Colour / finishingStainless steel, brushed; serigraphy colour black; applied logo

ExtractionDucted out or re–circulation possible

Control settingControl knobs, Portofino style, steel effect, 2 controls

Number of speeds3 speeds + intensive speed

Number of lights2

Light typeLED, 2 W each, 4000 K colour temperature

Free outlet maximum capacity815 m³/h

Motor power275 W

Number of filters3 stainless steel anti-grease filters

Vent outlet150 mm, with non return valve

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Extraction rate IEC 61591 – Speed 1288 m³/h – 48 dBA

Extraction rate IEC 61591 – Speed 2421 m³/h – 63 dBA

Extraction rate IEC 61591 – Speed 3630 m³/h – 67 dBA

Extraction rate IEC 61591 – Intensive speed781 m³/h – 72 dBA

Annual Efficiency Consumption (AEChood)40 kWh/year

Energy efficiency class (EEC)A+

Fluid Dynamic Efficiency (FDE)36,2

Fluid Dynamic Efficiency class (FDEC)A

Lighting Efficiency (LE)78,2 lux/W

Lighting Efficiency Class (LEC)A

Grease Filtering Efficiency (GFE)78,5 %

Grease Filtering Efficiency Class (GFEC)C

Air flow at minimum speed (Qmin)288 m³/h

Maximum extraction rate630 m³/h

Intensive extraction rate781 m³/h

Airbourne acoustical A–weighted sound power emission at minimum speed (SPEmin)48 dBA

Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)67 dBA

Airbourne acoustical A–weighted sound power emission at boost speed (SPEboost)72 dBA

Time increase factor (F)1,00

Energy Efficiency Index40,3

Measured air flow rate at best efficiency point (Qbep)413 m³/h

Measured air pressure at best efficiency point (Qbep)476 Pa

Measured electric power input at best efficiency point (Wbep)151 W

Normal power of the light system (Wl)2 W

Average illumination of the light on the cooking surface (Emiddle)172 lux

Sound power level at highest setting (Lwa)67 dBA

Nominal power277 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1000 mm

Alternative colours availableWhite, Black, Anthracite, Yellow, Green, Red, Orange

Available colour codesKPF9WH, KPF9BL, KPF9AN, KP9YW, KPF9OG, KPF9RD, KPF9OR

Downloads

Download product documentation, manuals, and specification sheets.

KPF9X - Bulletin.pdf

PDF

KPF9X Spec

PDF

Frequently Asked Questions

Can this hood be used in both ducted and recirculation modes?

Yes. The extraction system allows for ducted out or re–circulation operation.

What is the maximum and intensive extraction rate?

The maximum extraction rate is 630 m³/h, while the intensive extraction rate reaches 781 m³/h. The free outlet maximum capacity is 815 m³/h.

How energy efficient is the SMEG KPF9X hood?

The hood has an A+ energy efficiency class with an Annual Efficiency Consumption of 40 kWh/year. It is stated that A+ helps to save up to 10 % energy compared to class A, with maximum performance and minimum consumption guaranteed.

What type of filters does this cooker hood use?

The hood is equipped with 3 stainless steel anti-grease filters. Compatible charcoal filter accessories include FLT6 round charcoal filters (kit 2 pieces) and the KITALLFC universal charcoal filter in Stainless Steel AISI 304.

What are the minimum installation heights above the hob?

The minimum distance from a gas hob is 750 mm, and the minimum distance from an electric hob is 650 mm.

What lighting does the hood provide?

The hood has 2 LED lights of 2 W each, with a colour temperature of 4000 K. Lighting Efficiency is 78,2 lux/W with Lighting Efficiency Class A, and the average illumination on the cooking surface is 172 lux.
