Smeg KPF9RD Portofino Chimney Hood

The SMEG KPF9RD is a 90 cm Portofino chimney cooker hood in red, designed for ducted extraction or recirculation. Made from brushed stainless steel and painted material, it offers three speeds plus an intensive setting, with a maximum intensive extraction rate of 781 m³/h. LED lighting with a 4000 K colour temperature illuminates the cooking area, while stainless steel anti-grease filters help remove grease from steam during cooking. The hood is rated A+ for energy efficiency.

SKU:KPF9RD

EAN:8017709236311

Category::Cooker Hoods

Quantity:

Key Features

90 cm chimney cooker hood from the Portofino product family with chimney design.

Ducted out or re–circulation operation for flexible installation options.

Red Portofino aesthetics with brushed stainless steel and painted material finish.

Three speeds plus intensive speed for extra fast extraction when required.

Maximum extraction rate 630 m³/h and intensive extraction rate 781 m³/h.

Free outlet maximum capacity 815 m³/h with 275 W motor power.

A+ energy efficiency class with annual efficiency consumption of 40 kWh/year.

LED lighting, 2 × 2 W with 4000 K colour temperature and lighting efficiency class A.

Stainless steel anti–grease filters to help remove grease from cooking steam.

Non return valve and 150 mm vent outlet.

Noise level from 48 dBA to 67 dBA depending on selected speed, with 72 dBA at intensive speed.

Control knobs with Portofino design and steel effect colour, with 2 controls.

Minimum distance 750 mm from gas hobs and 650 mm from electric hobs.

Energy efficient airflow with fluid dynamic efficiency class A and energy efficiency index 40,3.

Average illumination 172 lux on the cooking surface.

Compatible charcoal filter accessories available: FLT6 and KITALLFC.

Alternative colours available including white, black, stainless steel, anthracite, yellow, green and orange.

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

ExtractionDucted out or re–circulation possible

MaterialStainless Steel + Painted Material

Type of steelBrushed

EAN code8017709236311

Hood width90 cm

AestheticsPortofino

ColourRed

Serigraphy colourBlack

LogoApplied

Control settingControl knobs

Number of controls2

Control knobs typePortofino

Controls colourSteel effect

Number of speeds3 + intensive speed

Number of lights2

Light typeLED

Light power2 W

Light colour temperature4000 K

Free outlet maximum capacity815 m³/h

Motor power275 W

Number of filters3

Anti–grease filtersStainless steel

Vent outlet150 mm

Minimum distance from gas hob750 mm

Minimum distance from electric hob650 mm

Non return valveYes

Extraction rate (IEC 61591) – Speed 1288 m³/h

Noise level (IEC 60704–2–13) – Speed 148 dBA

Extraction rate (IEC 61591) – Speed 2421 m³/h

Noise level (IEC 60704–2–13) – Speed 263 dBA

Extraction rate (IEC 61591) – Speed 3630 m³/h

Noise level (IEC 60704–2–13) – Speed 367 dBA

Extraction rate (IEC 61591) – Intensive speed781 m³/h

Noise level (IEC 60704–2–13) – Intensive speed72 dBA

Annual efficiency consumption (AEChood)40 kWh/year

Energy efficiency class (EEC)A+

Fluid dynamic efficiency (FDE)36,2

Fluid dynamic efficiency class (FDEC)A

Lighting efficiency (LE)78,2 lux/W

Lighting efficiency class (LEC)A

Grease filtering efficiency (GFE)78,5 %

Grease filtering efficiency class (GFEC)C

Air flow at minimum speed (Qmin)288 m³/h

Maximum extraction rate630 m³/h

Intensive extraction rate781 m³/h

Sound power emission at minimum speed (SPEmin)48 dBA

Sound power emission at maximum speed (SPEmax)67 dBA

Sound power emission at boost speed (SPEboost)72 dBA

Time increase factor (F)1,00

Energy efficiency index per first cavity40,3

Measured air flow rate at best efficiency point (Qbep)413 m³/h

Measured air pressure at best efficiency point (Qbep)476 Pa

Measured electric power input at best efficiency point (Wbep)151 W

Normal power of the light system (Wl)2 W

Average illumination of the light on the cooking surface (Emiddle)172 lux

Sound power level at highest setting (Lwa)67 dBA

Nominal power277 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1000 mm

Alternative colours availableWhite, Black, Stainless steel, Anthracite, Yellow, Green, Orange

Available colour codesKPF9WH – KPF9BL – KPF9X – KPF9AN – KPF9YW – KP9OG – KPF9OR

Compatible accessoriesFLT6; KITALLFC

Downloads

Download product documentation, manuals, and specification sheets.

KPF9RD - Bulletin.pdf

PDF

KPF9RD Spec

PDF

Frequently Asked Questions

What are the extraction options for this hood?

The hood supports ducted out extraction or re–circulation, allowing it to be configured according to the kitchen setup.

How powerful is the SMEG KPF9RD?

It has a free outlet maximum capacity of 815 m³/h, a maximum extraction rate of 630 m³/h and an intensive extraction rate of 781 m³/h, powered by a 275 W motor.

What is the energy efficiency rating?

The hood has an A+ energy efficiency class, with an annual efficiency consumption of 40 kWh/year and energy efficiency index of 40,3.

What types of filters does it use?

The hood is fitted with stainless steel anti–grease filters to help remove grease from cooking steam. It is compatible with FLT6 round charcoal filters and the KITALLFC universal charcoal filter in stainless steel AISI 304.

How bright is the lighting on the cooking surface?

The LED lighting system has a power of 2 W and provides an average illumination of 172 lux on the cooking surface, with a lighting efficiency of 78,2 lux/W and class A rating.

What are the noise levels at different speeds?

At minimum speed the sound power emission is 48 dBA, at maximum speed it is 67 dBA, and at intensive/boost speed it reaches 72 dBA.
