Smeg KPF12RD Portofino Chimney Hood

The SMEG Portofino KPF12RD is a 120 cm red chimney cooker hood designed for ducted or re-circulation extraction. Finished in brushed stainless steel and painted material, it features LED lighting, stainless steel anti-grease filters and knob controls with 3 speeds plus intensive. With a maximum free outlet capacity of 815 m³/h and an A+ energy efficiency class, it offers effective extraction and stylish Portofino aesthetics for larger cooking areas.

SKU:KPF12RD

EAN:8017709261665

Category::Cooker Hoods

Quantity:

Key Features

Product type: Chimney cooker hood from the Hood product family.

Model code: KPF12RD with Portofino aesthetics and applied logo.

Width: 120 cm hood width, suitable for larger cooking areas.

Colour & finish: Red colour in brushed stainless steel and painted material.

Extraction options: Ducted out or re-circulation possible with non return valve.

Controls: Portofino control knobs, steel effect, with 2 controls and 3 speeds plus intensive speed.

Lighting: 4 LED lights, 4 W each, 4000 K colour temperature.

Filters: 4 stainless steel anti-grease filters to help remove grease from cooking steam.

Maximum extraction: Free outlet maximum capacity 815 m³/h.

Extraction rate (IEC 61591): 287 m³/h (speed 1), 389 m³/h (speed 2), 606 m³/h (speed 3), 777 m³/h (intensive).

Noise levels (IEC 60704-2-13): 49 dBA (speed 1), 58 dBA (speed 2), 67 dBA (speed 3), 73 dBA (intensive).

Energy efficiency: A+ energy efficiency class with 42 kWh/year annual efficiency consumption.

Lighting performance: Lighting Efficiency 74,8 lux/W, Lighting Efficiency Class A, average illumination on cooking surface 329 lux.

Grease filtering performance: Grease Filtering Efficiency 74,9 %, Grease Filtering Efficiency Class D.

Vent outlet: 150 mm vent outlet for connection to ducting.

Minimum hob distance: 650 mm minimum distance from gas hob and 650 mm from electric hob.

Electrical connection: Nominal power 280 W, motor power 275 W, 220–240 V, 50–60 Hz.

Available colours: Also available in White, Black, Stainless steel and Turquoise (models KPF12WH/BL/X/T).

Compatible accessories: FLT6 round charcoal filters kit (2 pieces) and KITALLFC universal charcoal filter Stainless Steel AISI 304.

Technical Spec

Product familyHood

Hood typeChimney Cooker Hoods

DesignChimney

ExtractionDucted out or re-circulation possible

MaterialStainless Steel + Painted Material

Type of steelBrushed

EAN code8017709261665

Hood width120 cm

AestheticsPortofino

ColourRed

Serigraphy colourBlack

LogoApplied

Control settingControl knobs

No. of controls2

Control knobsPortofino

Controls colourSteel effect

No. of speeds3 + Intensive speed

No. of lights4

Light typeLED

Light power4 W

Light colour temperature4000 K

Free outlet maximum capacity815 m³/h

Motor power275 W

No. of filters4

Anti-grease filtersStainless steel

Vent outlet150 mm

Minimum distance from gas hob650 mm

Minimum distance from electric hob650 mm

Non return valveYes

Extraction rate IEC 61591 – Speed 1287 m³/h

Noise level IEC 60704-2-13 – Speed 149 dBA

Extraction rate IEC 61591 – Speed 2389 m³/h

Noise level IEC 60704-2-13 – Speed 258 dBA

Extraction rate IEC 61591 – Speed 3606 m³/h

Noise level IEC 60704-2-13 – Speed 367 dBA

Extraction rate IEC 61591 – Intensive speed777 m³/h

Noise level IEC 60704-2-13 – Intensive speed73 dBA

Annual Efficiency Consumption (AEChood)42 kWh/year

Energy efficiency class (EEC)A+

Fluid Dynamic Efficiency (FDE)36,3

Fluid Dynamic Efficiency class (FDEC)A

Lighting Efficiency (LE)74,8 lux/W

Lighting Efficiency Class (LEC)A

Grease Filtering Efficiency (GFE)74,9 %

Grease Filtering Efficiency Class (GFEC)D

Air flow at minimum speed (Qmin)287 m³/h

Maximum extraction rate606 m³/h

Intensive extraction rate777 m³/h

Airborne acoustical A-weighted sound power emission at minimum speed (SPEmin)49 dBA

Airborne acoustical A-weighted sound power emission at maximum speed (SPEmax)67 dBA

Airborne acoustical A-weighted sound power emission at boost speed (SPEboost)73 dBA

Sound power level at highest setting (Lwa)67 dBA

Time increase factor (F)0,7

Energy Efficiency Index per first cavity41,4

Measured air flow rate at best efficiency point (Qbep)400 m³/h

Measured air pressure at best efficiency point (Qbep)490 Pa

Measured electric power input at best efficiency point (Wbep)150 W

Normal Power of the light system (Wl)4 W

Average illumination on cooking surface (Emiddle)329 lux

Nominal power280 W

Voltage220–240 V

Frequency (Hz)50–60 Hz

Power supply cable length1000 mm

Alternative colours availableWhite, Black, Stainless steel, Turquoise

Available colours modelsKPF12WH/BL/X/T

Compatible accessory – FLT6Round Charcoal filters (kit 2 pieces)

Compatible accessory – KITALLFCUniversal Charcoal filter Stainless Steel AISI 304 – filter can be washed in dishwasher 50 °C (water and suitable detergent) and to dry it put in the oven 180 °C 25 minutes

Downloads

Download product documentation, manuals, and specification sheets.

KPF12RD - Bulletin.pdf

PDF

KPF12RD Spec

PDF

Frequently Asked Questions

Can this hood be used for both ducted and recirculation extraction?

Yes. Extraction is ducted out or re-circulation is possible. A non return valve is included, and compatible charcoal filters such as FLT6 and KITALLFC are available.

What is the minimum installation height above the hob?

The minimum distance from a gas hob is 650 mm and the minimum distance from an electric hob is also 650 mm.

How many speeds does the SMEG KPF12RD have?

The hood has 3 speeds plus an intensive speed, operated via Portofino control knobs with steel effect finish.

What is the energy efficiency rating of this hood?

The energy efficiency class is A+ with an annual efficiency consumption (AEChood) of 42 kWh/year.

What lighting does the hood use?

It is equipped with 4 LED lights of 4 W each, with a light colour temperature of 4000 K and Lighting Efficiency of 74,8 lux/W (Lighting Efficiency Class A).

How should the KITALLFC charcoal filter be cleaned?

The KITALLFC universal charcoal filter Stainless Steel AISI 304 can be washed in a dishwasher at 50 °C with water and suitable detergent. To dry it, it should be put in the oven at 180 °C for 25 minutes.
