Smeg KLT12L4X Ceiling Hood

The SMEG KLT12L4X is a 120 cm stainless steel ceiling cooker hood designed for ducted or re-circulation extraction. It features electronic touch controls, perimeter extraction and LED lighting with dimmer mode and adjustable colour temperature. With three speeds plus an intensive setting, 24 hour air filter function and Auto–Vent 2.0, it offers flexible performance. Aluminium anti-grease filters, a filter replacement indicator and remote control are also included.

SKU:KLT12L4X

EAN:8017709326203

Category::Cooker Hoods

Quantity:

Key Features

Ceiling cooker hood design – 120 cm wide ceiling installation with universal stainless steel aesthetics and brushed finishing.

Flexible extraction options – Suitable for ducted out installation or re–circulation, with a 150 mm vent outlet and non return valve.

Touch control with back–lighting – Electronic touch controls with back–lighted white interface for easy operation.

Three speeds plus intensive – 3 standard speeds and an intensive speed for extra fast extraction when required.

Perimeter extraction – Perimeter extraction panels designed to be very efficient and aid noise reduction.

24h air filter function – Refreshes the air for about 10 minutes every hour over 24 hours at minimum speed and an imperceptible noise level.

Auto–Vent 2.0 – Connection between hob and hood to manage extraction automatically (detail level beyond this name: Not stated in source).

LED lighting with dimmer – Two 7.4 W LED lights (total 14.8 W) with dimmer mode and adjustable colour temperature from 3000–5700 K.

Aluminium anti–grease filters – Four aluminium anti–grease filters with a dedicated replacement indicator warning light.

Remote control included – Supplied with a remote control for convenient operation.

Energy efficiency class B – Annual energy consumption of 91 kWh/year with energy efficiency class B.

Performance up to 591 m³/h – Intensive extraction rate of 591 m³/h, with a free outlet maximum capacity of 610 m³/h.

Noise levels from 51–71 dBA – Sound power emission of 51 dBA at minimum speed and 71 dBA at intensive speed.

Safe installation distances – Minimum distance of 650 mm from both gas and electric hobs.

Universal charcoal filter compatible – Compatible with optional charcoal filters KITALLFC and KITFCKLTR for recirculating use.

Technical Spec

Product familyHood

Hood typeCeiling Cooker Hoods

DesignCeiling

ExtractionDucted out or re–circulation possible

Electronic controlYes

Perimeter extractionYes

MaterialStainless steel, brushed (type of steel: Brushed)

Colour / FinishingStainless steel, brushed

AestheticsUniversal

LogoSilk screen

Model codeKLT12L4X

EAN code8017709326203

Hood width120 cm

Control settingTouch control back–lighted White

Number of speeds3 + Intensive speed

24h air filter functionYes

Time–setting optionsSwitch off automatically after end of cooking for a pre–set time

Auto–Vent 2.0Yes

Number of lights2

Light typeLED

Light power7,4 W (each); Normal power of light system (Wl) 14,8 W

Dimmer modeYes

Light colour temperature range3000–5700 K

Average illumination on cooking surface (Emiddle)298 lux

Motor power270 W

Nominal power305 W

Free outlet maximum capacity610 m³/h

Air flow at minimum speed (Qmin)194 m³/h

Maximum extraction rate447 m³/h

Intensive extraction rate591 m³/h

Extraction rate IEC 61591 – Speed 1194 m³/h

Extraction rate IEC 61591 – Speed 2315 m³/h

Extraction rate IEC 61591 – Speed 3447 m³/h

Extraction rate IEC 61591 – Intensive speed591 m³/h

Noise level IEC 60704–2–13 – Speed 151 dBA

Noise level IEC 60704–2–13 – Speed 257 dBA

Noise level IEC 60704–2–13 – Speed 365 dBA

Noise level IEC 60704–2–13 – Intensive speed71 dBA

Airbourne acoustical A–weighted sound power emission at minimum speed (SPEmin)51 dBA

Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)66 dBA

Airbourne acoustical A–weighted sound power emission at boost speed (SPEboost)71 dBA

Sound power level at highest setting (Lwa)66 dBA

Number of filters4

Anti–grease filtersAluminium

Filter replacement indicatorYes (warning light)

Vent outlet150 mm

Non return valveYes

Minimum distance from gas hob650 mm

Minimum distance from electric hob650 mm

Annual efficiency consumption (AEChood)91 kWh/year

Energy efficiency class (EEC)B

Fluid Dynamic Efficiency (FDE)27,1

Fluid Dynamic Efficiency class (FDEC)B

Lighting Efficiency (LE)20,1 lux/W

Lighting Efficiency Class (LEC)B

Grease Filtering Efficiency (GFE)62,7 %

Grease Filtering Efficiency Class (GFEC)E

Time increase factor (F)1,0

Energy Efficiency Index per first cavity63,0

Measured air flow rate at best efficiency point (Qbep)339,3 m³/h

Measured air pressure at best efficiency point (Qbep)632 Pa

Measured electric power input at best efficiency point (Wbep)219,5 W

Voltage220–240 V

Frequency50–60 Hz

Power supply cable length1500 mm

Accessories includedRemote control

Downloads

Download product documentation, manuals, and specification sheets.

KLT12L4X Spec

PDF

Frequently Asked Questions

Can this hood be used in re–circulation as well as ducted mode?

Yes. The extraction system allows for ducted out installation or re–circulation. For re–circulation, compatible charcoal filters such as KITALLFC or KITFCKLTR can be used.

What are the extraction rates at different speeds?

Air flow is 194 m³/h at minimum speed, 315 m³/h at speed 2, 447 m³/h at speed 3 and 591 m³/h at intensive speed. The free outlet maximum capacity is 610 m³/h.

How loud is the KLT12L4X during operation?

The sound power emission is 51 dBA at minimum speed and 66 dBA at maximum speed, with 71 dBA at boost/intensive speed. Perimeter extraction panels also aid noise reduction.

What energy efficiency rating does this hood have?

The hood has an energy efficiency class B, with an annual efficiency consumption (AEChood) of 91 kWh/year. Fluid Dynamic Efficiency class is B and Lighting Efficiency class is also B.

How are the filters maintained and when should they be changed?

The hood uses aluminium anti–grease filters and offers a filter replacement indicator with warning lights to advise when filters need changing. Compatible charcoal filters KITALLFC and KITFCKLTR are dishwasher washable and can be dried in an oven following the specified temperature and time instructions.
