Miele PDR 508 HP Heat Pump Dryer

The Miele PDR 508 [EL] is a professional front‑loading vented dryer from the Little Giants range, designed for intensive use across a wide variety of commercial and residential settings. With an 8.0 kg load size, 130.00 l drum volume and electrically heated operation, it offers extremely short programme running times, including 8.0 kg dried in 84 minutes. Features such as PerfectDry, a stainless steel honeycomb drum and intelligent drum reversal support precise and gentle drying.

SKU:PDR508HP

EAN:4002516527985

Category::Dryers

Quantity:

Key Features

Professional vented dryer – Little Giants, electrically heated, with extremely short programme running times.

8.0 kg load capacity with a 130.00 l drum volume for efficient drying performance.

Performance 8.0 kg in 84 min for Cottons/Normal drying with residual moisture at 48 %.

Stainless steel honeycomb drum with SoftLift drum ribs for gentle fabric care.

PerfectDry for precision drying of all fabrics based on residual moisture control.

Language‑neutral fascia panel with rotary control – M Select, with language selection at any time.

Stackable front‑loader design in Lotus white with stainless steel fascia for space‑saving installation.

Wide application range – suitable for hotels, care homes, hospitals, laundries, small businesses, education, sports clubs and more.

Intelligent drum reversal and axial airflow for effective, even drying.

Large‑surface filter and drum lighting to support convenient operation.

Low temperature function for suitable fabric care where lower drying temperatures are required.

Programmable control system with residual moisture‑controlled user interface and 24 h delay start.

Energy efficiency class C with an annual energy consumption of 589 kWh.

Noise level 66 dB(A) in the Cottons Normal dry standard programme with a full load.

Recycling rate 95 % to support resource efficiency.

Connectivity options – payment system, peak‑load negotiation/energy management, LAN/WiFi module and WiFiConn@ct (all optional where stated).

Tested for intensive use for professional environments requiring unparalleled Miele quality.

Certifications and safety – CE, VDE, VDE‑EMC, UKCA, splash‑proof safety rating IPX4 and compliance with Machinery Directive 2006/42/EC.

Technical Spec

Product namePDR 508 [EL] Professional vented dryer, Little Giants, electrically heated

RangePerformance

Construction typeFront‑loader, stackable

Drying systemExhaust air (vented)

Front colourLotus white

Fascia colourStainless steel

Load capacity8.0 kg

Drum volume130.00 l

Door opening diameter370 mm

Door opening angle167°

Door hingeLeft

Stainless steel honeycomb drumYes

Maximum evaporation capacity2.60 l/hour

Specific energy consumption0.49 kWh/kg

Specific energy – Cottons/Normal (48 % residual moisture)0.49 kWh/kg

Specific energy – mixed fibre fabrics/Normal (40 % residual moisture)0.41 kWh/kg

Programme duration84 min

Programme duration – Cottons/Normal (48 % residual moisture)84 minutes

Programme duration – mixed fibre fabrics/Normal (40 % residual moisture)71 minutes

Control systemM Select

ProgrammabilityProgrammable

User interfaceResidual moisture controlled

Max. delay start24 h

Time left displayYes

Programme sequence indicatorYes

Control panel symbolsEasy‑to‑understand symbols

Language selectionLanguage can be selected easily at any time

Heating typeElectric

Electrical connection230V~ 50/60HZ

Electric heater rating2.76 kW

Total connected load2.99 kW

Fuse rating13 A

External height850 mm

External width596 mm

External depth717 mm

Gross height940 mm

Gross width660 mm

Gross depth820 mm

Net weight49.0 kg

Gross weight54 kg

Maximum floor load920 N

Emission sound pressure level in the workplace≤70 dB(A) re 20 µPa

Heat dissipation into the room0.76 MJ/h

Energy efficiency classC

Annual energy consumption589 kWh

Noise – Cottons Normal dry standard programme, full load66 dB(A)

Duration – standard programme115 minutes

How it worksVented

Recycling rate95 %

Payment systemOptional

Optical interface for service accessYes

Peak‑load negotiation / energy managementOptional

LAN/WiFi moduleOptional

WiFiConn@ctYes

CEYes

VDEYes

VDE‑EMCYes

Splash‑proof safety ratingIPX4

WEEEYes

UKCAYes

Machinery DirectiveComplies with Machinery Directive 2006/42/EC

EAN4002516527985

Material number11945020

Old material number52508353GB

Downloads

Download product documentation, manuals, and specification sheets.

PDR508HP Spec

PDF

Frequently Asked Questions

What is the load capacity of the Miele PDR 508 [EL]?

The PDR 508 [EL] has a load size of 8.0 kg with a drum volume of 130.00 l.

How long does a standard drying programme take?

For Cottons/Normal with residual moisture at 48 %, the programme duration is 84 minutes for an 8.0 kg load. The duration of the standard programme is listed as 115 minutes.

Is this dryer suitable for commercial use?

Yes. It is a professional vented dryer from the Performance range, tested for intensive use, and is suitable for multiple commercial sectors including hotels, care homes, hospitals, laundries, small businesses and more.

What type of power supply does the PDR 508 [EL] require?

The dryer is electrically heated and requires a 230V~ 50/60HZ electrical connection, with a total connected load of 2.99 kW and a 13 A fuse rating.

Does the machine offer connectivity and payment options?

The dryer includes a communication slot, an optical interface for service access, and optional payment system, peak‑load negotiation/energy management and LAN/WiFi module, as well as WiFiConn@ct.

What safety and certification standards does it meet?

The PDR 508 [EL] carries CE, VDE, VDE‑EMC, WEEE and UKCA markings, has a splash‑proof safety rating of IPX4 and complies with Machinery Directive 2006/42/EC.
