The Liebherr WPbl 4601 GrandCru is a dedicated wine storage fridge designed for storing wine in optimal conditions. With a capacity of up to 166 Bordeaux bottles and a temperature range from +5 °C to +20 °C, it offers flexible storage for wine collections. Features such as convection cooling with FreshAir activated charcoal filter, LED ceiling lighting and touch electronic controls make it suitable for wine enthusiasts seeking controlled storage at home or in professional environments.

Key Features

Wine storage capacity: holds a maximum of 166 Bordeaux bottles (0.75 l) as per norm NF H 35-124.
Single temperature zone: 1 temperature zone with an adjustable range from +5 °C to +20 °C.
Convection cooling with FreshAir filter: forced air system with fresh air supply via FreshAir activated charcoal filter.
Energy performance: energy efficiency class ¹ (exact class Not stated in source); energy consumption 111 kWh per 365 days / 0.304 kWh per 24 h ¹.
Low noise operation: noise output of 38 dB(A).
Climate rating: SN–ST for ambient temperatures from +10 °C to +38 °C.
Design and finish: glass door with black frame, black side walls and Slimline black handle.
LED ceiling lighting: permanently on and dimmable interior light for the wine compartment.
Touch electronic controls: LC monochrome display in the door with digital temperature display.
Safety features: visual and acoustic alarm in case of malfunction, visual and acoustic door alarm and child proof function.
Flexible storage: 5 adjustable beech wood storage shelves.
Door configuration: reversible door hinging on the right, with lock mechanically retrofittable.
Smart connectivity ready: SmartDeviceBox available as an optional accessory.
Total storage volume: 328 l ³ for wine storage.

Technical Specifications

Product type	Wine storage fridge – GrandCru
Model name	WPbl 4601
Energy efficiency class	¹ (exact class Not stated in source)
Energy consumption	111 / 0.304 kWh (365 days / 24 h) ¹
Maximum number of Bordeaux bottles (0.75 l)	166 ²
Total volume	328 l ³
Noise output	38 dB(A)
Climate rating	SN–ST (+10 °C to +38 °C)
Door	Glass door, frame black
Side walls	black
Exterior dimensions (h / w / d)	148.4 / 59.7 / 76.3 cm ¹
Control type	LC monochrome display in the door, touch electronic
Digital temperature display	Yes
Alarm in case of malfunction	Visual and acoustic
Door alarm	Visual and acoustic
Child proof function	Yes
Temperature zones	1
Temperature range	+5 °C to +20 °C
Adjustable cooling circuits	1
Forced air system	Convection cooling, fresh air supply via FreshAir activated charcoal filter
Interior light	LED ceiling lighting permanently on, dimmable
Handle	Slimline handle, black
Interface	SmartDeviceBox: optional accessory
Shelf material	Adjustable beech wood shelves
Number of storage shelves	5
Door hinges	Reversible door hinging, right
Lock	Mechanically retrofittable
EAN number	9005382243978

¹ To achieve the indicated energy consumption level, the wall spacers provided with the appliance must be used. These increase the appliance depth by approximately 1.5 cm. If the wall spacers are not used, the appliance will remain fully functional, but will have a slightly higher energy consumption level.

² These models are only bound for storing wine. Maximum DIN norm Bordeaux bottles capacity (0.75 l) as per norm NF H 35-124 (H: 300.5 mm, Ø 76.1 mm).

³ In accordance with Regulation EU 2019/2016 the total volume is indicated to the nearest integer (rounded off) and the volume of the frozen compartments and refrigeration compartments to one place after the decimal point.

Additional Details and Usage

The appliance is designed exclusively for storing wine, with capacity based on DIN norm Bordeaux bottles. The single temperature zone can be set between +5 °C and +20 °C using the touch electronic controls with LC monochrome display in the door, which also provides a digital temperature readout.

Convection cooling with a FreshAir activated charcoal filter ensures a fresh air supply within the cabinet. The LED ceiling lighting is permanently on and dimmable, offering clear visibility of the stored bottles. Adjustable beech wood shelves allow flexible arrangement of up to 5 storage levels.

Visual and acoustic alarms signal both malfunctions and door openings, and a child proof function is included. Door hinging is on the right but is reversible, and a mechanical lock can be retrofitted if required. The SmartDeviceBox interface is available as an optional accessory for connectivity functions (details Not stated in source).

Frequently Asked Questions

How many wine bottles can the Liebherr WPbl 4601 store?

The appliance can store a maximum of 166 DIN norm Bordeaux bottles (0.75 l) as per norm NF H 35-124, with bottle dimensions H: 300.5 mm and Ø 76.1 mm. Capacity refers specifically to wine bottles of this standard size.

What temperature range can be set for wine storage?

The WPbl 4601 has one temperature zone with an adjustable range from +5 °C to +20 °C. Temperature is set and monitored via the LC monochrome display in the door with touch electronic controls and digital temperature display.

Is this appliance suitable for environments with varying room temperatures?

The climate rating is SN–ST, meaning the appliance is designed to operate in ambient temperatures from +10 °C to +38 °C. Within this range, it can maintain the selected internal storage temperature for wine.

What alarms and safety features are included?

The wine storage fridge has visual and acoustic alarms for malfunctions and for the door. It also includes a child proof function. A lock is not supplied as standard but can be mechanically retrofitted.

How does the energy consumption depend on installation?

To achieve the indicated energy consumption level of 111 kWh per 365 days, the wall spacers provided with the appliance must be used. These increase the appliance depth by approximately 1.5 cm. If the wall spacers are not used, the appliance remains fully functional but will have a slightly higher energy consumption level.
