Bosch Series 2 SMV2HTX02G Dishwasher

The Bosch SMV2HTX02G is a Series 2 fully–integrated 60 cm dishwasher designed for built–in installation with a 13 place setting capacity. It offers connected convenience via Home Connect, allowing remote start and add–on functions such as Silence on Demand. With Extra Dry, SpeedPerfect+ and AquaStop, it combines flexible programmes, efficient drying and water protection for everyday dishwashing in modern kitchens.

SKU:SMV2HTX02G

EAN:4242005270330

Category::Dishwashers

Quantity:

Key Features

Series 2 fully–integrated 60 cm design – built–in installation with stainless steel/Polinox interior and InfoLight floor projection.

Connected dishwasher with Home Connect – WLAN–enabled for flexible control, Remote Start and additional functions.

Silence on Demand via app – up to 30 minutes of noise reduction available as an add–on function.

Extra Dry option – extra drying setting for difficult–to–dry loads.

SpeedPerfect+ – reduced washing time with perfectly cleaned dishes.

13 place settings capacity – suitable for everyday family dishwashing.

Energy Efficiency Class D – 84 kWh per 100 cycles in Eco 50 °C with 9 litres water per cycle.

Quiet operation – airborne acoustical noise emissions of 46 dB(A) re 1 pW, Noise Efficiency Class C.

AquaStop – Bosch’s warranty in case of water damage throughout the lifetime of the appliance (terms not stated in source).

5 main programmes – Eco 50 °C, Auto 45–65 °C, Intensive 70 °C, Express 65 °C and Favourite.

Special options – Remote Start, Extra Dry, Half Load and SpeedPerfect+.

Machine Care programme – helps maintain the appliance.

Flexible basket system – normal baskets, low friction wheels, rack stopper, knife rack, cutlery basket, cup shelf and glass holder.

EcoSilence BLDC drive – brushless motor technology for efficient operation.

Heat exchanger drying – hygienic and efficient drying performance.

DosageAssist and automatic detergent detection – designed for optimal use of detergent.

AquaSensor III and AquaMix – load sensing and glass protection system.

Time delay function – 3, 6 or 9 hour start delay with acoustic end–of–cycle indicator.

Self–cleaning filter system – 3 piece corrugated filter for easier maintenance.

Steam protection for worktop included – helps protect surrounding furniture.

Optional accessories available – including decorative strips, attachment door, rack inserts, hose extensions, connection rail and GlassSecure Tray.

Technical Spec

Product name / modelSeries 2, Fully–integrated dishwasher, 60 cm – SMV2HTX02G

Installation typologyIntegrated, Built–in

Energy Efficiency ClassD (scale A to G)

Energy consumption (Eco 50 °C)84 kWh per 100 cycles

Water consumption (Eco 50 °C)9.0 litres per cycle

Programme duration (Eco 50 °C)4:30 h

Capacity13 place settings

Airborne acoustical noise46 dB(A) re 1 pW

Noise emission classC

Dimensions (H x W x D)81.5 x 59.8 x 55 cm

Required niche size (H x W x D)815–875 x 600 x 550 mm

Depth with door open 90°1150 mm

Adjustable feetYes – all from front, max. 60 mm

Adjustable plinthBoth horizontal and vertical

Height of removable worktop0 mm

Net / gross weight32.3 kg / 34.1 kg

Connection rating2400 W

Fuse protection10 A

Voltage220–240 V

Frequency50; 60 Hz

Electrical supply cord length175 cm

Plug typeGB plug

Inlet hose length165 cm

Outlet hose length190 cm

EAN code4242005480166

Downloads

Download product documentation, manuals, and specification sheets.

SMV2HTX02G Spec

PDF

Frequently Asked Questions

What is the capacity of the Bosch SMV2HTX02G dishwasher?

The Bosch SMV2HTX02G has a capacity of 13 place settings.

Which programmes are available on this dishwasher?

It offers 5 programmes: Eco 50 °C, Auto 45–65 °C, Intensive 70 °C, Express 65 °C and Favourite. The default Favourite programme is Pre–Rinse. There is also a Machine Care programme.

Does the SMV2HTX02G support Home Connect and remote control?

Yes. The dishwasher is Home Connect ready on WLAN, supports Remote Start and add–on functions via the Home Connect app, including Hygiene+ and Silence on Demand.

How energy and water efficient is the Eco programme?

In the Eco 50 °C programme, the appliance uses 84 kWh per 100 cycles and 9.0 litres of water per cycle. The programme duration is 4:30 h and the Energy Efficiency Class is D.

What is the noise level during operation?

The airborne acoustical noise emissions are 46 dB(A) re 1 pW, with a Noise Efficiency Class of C. A Silence on Demand function via the app offers up to 30 minutes of additional noise reduction.

What safety features does this dishwasher have?

The SMV2HTX02G includes AquaStop, providing Bosch’s warranty in case of water damage for the lifetime of the appliance (full warranty terms not stated in source). It also features steam protection for the worktop and a self–cleaning filter system with a 3 piece corrugated filter.
