Blanco Evol-S Pro Hot 4 in 1 Boiling Pull Out Tap

The BLANCO drink.filter EVOL-S Pro is a 3-in-1 semi-professional mixer tap providing cold, warm and filtered ambient cold water. Designed for convenient water consumption on demand, it combines Click + Touch operation with a high-end BWT multi-stage filter that reduces lime and improves taste. With separate outlets for purified and mixed water, dual-spray functionality and a black matt surface finish, it suits users seeking refined drinking water and flexible kitchen tap performance.

SKU:EVOLSPROHOTFILTERBM

EAN:

Category::Taps

Quantity:

Key Features

3-in-1 semi-professional mixer tap providing cold, warm and filtered ambient cold water.

Click + Touch control with accurate scaling wheel and intuitive touch operation for predefined conditioned water type and volume in ml.

High-end BWT multi-stage filter reduces lime and improves taste for refined drinking water.

Separate outlet for purified drinking water via a 180° swivel spout for refined water.

360° swivel spout for mixed water for flexible use around the sink area.

Dual spray with magnetic holder featuring a two-jet shower for mixed water and a precise magnetic holder.

Black matt surface finish designed to precisely match the surrounding kitchen environment.

Patented jet regulator for markedly reduced scaling in everyday use.

Ceramic disk cartridge for the mixer tap mechanism.

Flexible connector pipes 700 mm long with ⅜'' nut for connection.

Stabilisation plate included to increase tap stability when fitted in stainless steel sinks.

Non-return valve integrated and guaranteed against reflux in accordance with EN 171.

Control box with integrated display shows remaining filter capacity for timely filter replacement.

Complete filtering system included with 1 Drink Filter Soft L, 1 filter head and 1 control box in the scope of supply.

High-end water filtering system by BWT with filter head and multi-stage filter cartridge.

Ø 35 mm tap hole required for installation.

Power supply 220–240 V AC/50 Hz for the control box and display.

Technical Spec

Product namedrink.filter EVOL-S Pro

Item number526636

Tap type3-in-1 semi-professional tap (ambient cold and warm, filtered ambient cold)

Water functionsCold, warm and filtered ambient cold water

Filter systemHigh-end BWT multi-stage filter with filter head and cartridge

Included filter1 Drink Filter Soft L

Control boxControl box with integrated display for remaining filter capacity

Power supply220–240 V AC/50 Hz

OperationClick and Touch with scaling wheel and intuitive touch control

Spout for refined waterSeparate 180° swivel spout

Spout for mixed water360° swivel spout with two-jet shower and magnetic holder

Tap hole requirementØ 35 mm tap hole required

Cartridge typeCeramic disk cartridge

Jet regulatorPatented jet regulator for markedly reduced scaling

Connector pipesFlexible connector pipes, 700 mm long, ⅜'' nut

StabilisationStabilisation plate to increase tap stability in stainless steel sinks

Backflow protectionNon-return valve, guaranteed against reflux in accordance with EN 171

Surface finishBlack matt surface finish

DimensionsFrom side view diagram (tap body and spout): overall height 447 mm; spout reach for mixed water 211 mm; upper hose reach 252 mm; mixed water outlet height approx. 196 mm; body height to outlet approx. 182 mm; body diameter Ø 48 mm; base depth 62 mm; handle clearance max. 60 mm; additional offset 112 mm and 83 mm as shown.

Swivel rangeDiagram indicates swivel ranges for spouts (exact angles not numerically stated).

Downloads

Download product documentation, manuals, and specification sheets.

EVOLSPROHOTFILTERBM Spec

PDF

Frequently Asked Questions

What types of water does the drink.filter EVOL-S Pro provide?

It is a 3-in-1 semi-professional tap that provides ambient cold water, warm water and filtered ambient cold water.

How is the filtered water controlled and dispensed?

Filtered water is controlled using Click and Touch operation. A scaling wheel and intuitive touch control allow selection of predefined conditioned water types and exact volumes in millilitres, with a separate 180° swivel spout for refined water.

What filtration technology is used in this system?

The system uses a high-end BWT multi-stage filter with a filter head and cartridge. It is stated to reduce lime and improve taste. One Drink Filter Soft L is included in the scope of supply.

What electrical supply is required for the control box?

The control box, which features an integrated display for remaining filter capacity, requires a power supply of 220–240 V AC/50 Hz.

What installation requirements should be considered?

Installation requires a Ø 35 mm tap hole. The tap is supplied with flexible connector pipes (700 mm long, ⅜'' nut), a stabilisation plate for stainless steel sinks, and an integrated non-return valve that is guaranteed against reflux in accordance with EN 171.
