The Smeg SFR9302TX is a reduced height 90 cm Classica electric oven in brushed stainless steel with fingerproof finishing and Eclipse glass. It offers thermo-ventilated cooking with 10 main functions, Vapor Clean and rapid pre-heating. With a net cavity volume of 85 l, A+ energy efficiency and Ever Clean enamel, it suits users seeking a spacious yet compact-height built-in oven with flexible programmes, electronic temperature control and classic knob and touch controls.

Key Features

Reduced height 90 cm design for compact kitchen sets of small height while maintaining generous oven capacity.
Thermo-ventilated electric cooking with heat from multiple directions and active fan for quick, even results.
10 main cooking functions including Static, Fan assisted, Circulaire, Turbo, Eco, Large grill, Fan grill (large), Base, Circulaire + bottom and Pizza.
Vapor Clean system uses steam to loosen deposits in the cavity for easier cleaning.
Ever Clean enamel cavity with low porosity, acid resistance and a bright finish to reduce fat adhesion and simplify maintenance.
A+ energy efficiency class with energy efficiency index of 80,2 % for lower consumption compared to class A.
Large usable volume with 70 l stated capacity and 85 l net cavity volume, plus four cooking levels.
EvoScreen LCD display with optimised colour graphics and 5 touch buttons for simple control of functions and parameters.
Knobs & touch buttons controls featuring classic control knobs and steel-effect finish.
Cool door with Fresh Touch triple-glazed door and tangential cooling to help maintain outer door temperature below 50°C.
Soft Close door hinges for smooth and quiet door closing.
Electronic temperature control maintains oven temperature with approximately 2–3 °C precision for sensitive dishes.
Rapid pre-heating option reduces preheat time by up to 50 %.
Leavening (proving) function providing air at 40 °C for yeast dough mixes.
Sabbath function to cook food while respecting Judaism's day of rest provisions.
Child lock / control lock to prevent accidental programme changes.
Halogen lighting with side lights and automatic lighting deactivation for improved visibility and energy saving.
Stainless steel Classica aesthetic with flat design, classic handle in inox and embossed logo.
Four shelf levels with accessories including rack with back stop, enamelled deep tray, insert grid and telescopic guide rails (total extraction).
Flexible options such as Keep warm, Eco light, brightness adjustment, tones and showroom demo option.

Technical Specifications

Model	SFR9302TX
Category	Reduced height 90 cm
Product family	Oven
Power supply	Electric
Heat source	ELECTRICITY
Cooking method	Thermo-ventilated
Cleaning system	Vapor Clean
EAN code	8017709326548
Aesthetic	Classica
Colour	Stainless steel
Finishing	Fingerproof
Design	Flat
Material	Stainless steel
Type of steel	Brushed
Glass type	Eclipse
Serigraphy colour	Black
Serigraphy type	Symbols
Door design	With 2 horizontal strips
Handle style	Classic
Handle colour	Inox
Logo	Embossed
Control knobs	Classic
Controls colour	Steel effect
Display name	EvoScreen
Display technology	LCD
Control setting	Knobs & touch buttons
Number of controls	2
Number of cooking functions	10
Traditional cooking functions	Static; Fan assisted; Circulaire; Turbo; Eco; Large grill; Fan grill (large); Base; Circulaire + bottom; Pizza
Other functions	Defrost by time; Leavening; Sabbath
Cleaning functions	Vapor Clean
Time-setting options	Delay start and automatic end cooking
Minute minder	Yes
Timer	1
Controls lock / Child safety	Yes
Other options	Keep warm; Eco light; Brightness; Tones
Showroom demo option	Yes
Rapid pre-heating	Yes
Capacity (Lt)	70 l
Net volume of the cavity	85 l
Minimum temperature	25 °C
Maximum temperature	280 °C
Number of shelves	4
Number of fans	2
Number of lights	2
Light type	Halogen
User-replaceable light	Yes
Light power	40 W
Light when door is opened	Yes
Lower heating element power	1700 W
Upper heating element power	1200 W
Grill element power	1700 W
Large grill power	2900 W
Circular heating element power	1550 W
Circular heating element 2 power	1550 W
Heating suspended when door is opened	Yes
Door opening type	Standard opening
Door	Cool
Removable door	Yes
Full glass inner door	Yes
Removable inner door	Yes
Total number of door glasses	3
Soft Close hinges	Yes
Cooling system	Tangential
Cooling duct	Double
Speed Reduction Cooling System	Yes
Usable cavity space dimensions (HxWxD)	283x724x418 mm
Temperature control	Electronic
Cavity material	Ever clean Enamel
Energy efficiency class	A+
Energy consumption per cycle (conventional)	0,73 kWh
Energy consumption in conventional mode	2,63 MJ
Energy consumption in forced air convection	4,50 MJ
Energy consumption per cycle (fan-forced convection)	1,25 kWh
Number of cavities	1
Energy efficiency index	80,2 %
Rack with back stop	1
Enamelled deep tray (40mm)	1
Insert grid	1
Telescopic guide rails, total extraction	1
Voltage	220-240 V
Plug	Not present
Current	14 A
Nominal power	3100 W
Frequency	50/60 Hz
Power supply cable length	150 cm
Compatible accessory – BNP608T	Teflon-coated tray, 8 mm depth, to be placed on the grid
Compatible accessory – GTP	Partially extractable telescopic guides (1 level), stainless steel
Compatible accessory – GTT	Totally extractable telescopic guides (1 level), stainless steel

Cooking Functions, Cleaning and Usage Details

Cooking programmes

The oven offers a wide range of traditional functions. Static uses upper and lower heat without fan for slower, more delicate cooking, suitable for roasts, fatty meats, bread and filled cakes. Fan assisted combines upper and lower heat with the fan for intense, homogeneous cooking, ideal for baked pasta, biscuits, roasts and cobblers. Base uses only the lower element without fan to complete cooking and crisp sweet and savoury pies, cobblers and pizzas.

Circulaire provides delicate, even heat from the back with fan, suitable for all dishes and multi-level cooking without mixing smells and flavours. Circulaire with lower element adds extra base heat for food requiring more cooking underneath. Turbo uses heat from above, below and the back with fan for quick cooking, even on several shelves. Eco is designed for low energy consumption on a single shelf and is recommended for foods that do not generate high moisture.

Grill delivers very intense heat from above only for excellent grilling and gratinating, especially for browning at the end of cooking. Fan grill combines intense top heat with fan for optimal grilling of thicker meats and large cuts. The Pizza function is specific for pizza in a pan, aiming for a soft interior and crispy exterior with well cooked, not burnt topping. Defrost by time is a manual defrost function that stops automatically at the end of the set duration.

Leavening and Sabbath functions

The Leavening function provides air at 40 °C to create an environment suitable for proving yeast-based doughs. Users select the function and place dough in the cavity for the allotted time. The Sabbath function allows food to be cooked while respecting Judaism's day of rest provisions.

Cleaning and maintenance

Vapor Clean is a simple cleaning function using steam to loosen deposits in the oven cavity. The Ever Clean enamel is applied electrostatically from corner to corner and baked at over 850 °C, creating a pyrolytic enamel that is resistant to acids and has lower porosity. This helps reduce fat adhesion during cooking and makes the oven walls and trays easier to maintain over time. The all glass inner door provides a flat surface that is simple to clean, and the inner door glass can be removed with a few quick movements.

Safety and cooling

The oven incorporates an air cooling system to help ensure safe surface temperatures. Fresh Touch technology, combining tangential cooling and internal heat-reflecting glasses, helps maintain the outer door surface below 50 °C and protects adjacent furniture from overheating. Heating is suspended when the door is opened. Triple-glazed doors and Soft Close hinges enhance both safety and user comfort.

Lighting and visibility

Two opposing side lights increase visibility inside the oven, assisted by halogen illumination. For energy saving, lighting is automatically deactivated after one minute from the start of cooking; this option can be disabled via the settings menu if continuous lighting is preferred.

Controls and timing

The EvoScreen display features optimised colour graphics and 5 touch buttons to control functions and parameters. Time management includes delay start and automatic end of cooking, a minute minder and one timer. Electronic control maintains internal temperature with approximately 2–3 °C precision, allowing preparation of dishes sensitive to temperature changes such as cakes, soufflés and puddings. Telescopic rails allow dishes to be pulled out for checking without fully removing them from the oven.

Frequently Asked Questions

What is the capacity of the SFR9302TX oven?

The oven has a stated capacity of 70 l and a net cavity volume of 85 l. The cavity provides four different cooking levels, supported by included accessories and telescopic guide rails.

Which cooking functions are available?

The oven offers 10 main functions: Static, Fan assisted, Circulaire, Turbo, Eco, Large grill, Fan grill (large), Base, Circulaire + bottom and Pizza. Additional functions include Defrost by time, Leavening and Sabbath.

How does the Vapor Clean system work?

Vapor Clean is a cleaning function that uses steam to loosen cooking deposits in the oven cavity. In combination with the Ever Clean enamel, which reduces fat adhesion, this makes the internal surfaces easier to clean and maintain.

What safety features does this oven include?

Safety features include a child lock for controls, an air cooling system, Fresh Touch cool door with triple glazing, heating suspension when the door is opened, Soft Close hinges and automatic lighting deactivation after one minute (adjustable via settings).

What is the energy rating and consumption?

The SFR9302TX has an A+ energy efficiency class. Energy consumption per cycle is 0,73 kWh in conventional mode and 1,25 kWh in fan-forced convection. Corresponding values are 2,63 MJ in conventional mode and 4,50 MJ in forced air convection, with an energy efficiency index of 80,2 %.

Which accessories are supplied and which are compatible?

Included accessories are one rack with back stop, one enamelled deep tray (40 mm), one insert grid and one set of telescopic guide rails with total extraction. Compatible accessories include the BNP608T Teflon-coated tray, and GTP and GTT telescopic guides (partially and totally extractable, 1 level, stainless steel).
