The Smeg CX92GM is a 90x60 cm Concert cooker combining a gas hob with two electric ovens, ideal for those wanting flexible, multilevel cooking. The main thermo–ventilated oven offers Vapor Clean, Circulaire and six cooking functions, while the second static oven adds extra capacity. With A energy efficiency for both cavities, easy clean enamel interiors, cast iron pan stands and a stainless steel Classic design, it suits kitchens needing performance and practicality.

Key Features

Cooker size 90x60 cm for generous hob space and dual oven capacity.
Dual electric ovens with 2 cavities carrying an energy label and both rated energy efficiency class A.
Hob type gas providing constant control of the heat source with immediate temperature change.
Thermo–ventilated main oven with Circulaire fan cooking for homogeneous and quicker cooking inside the cavity.
Static second oven offering additional traditional cooking capacity with 4 functions.
Vapor Clean system in the main oven, using steam to loosen food residue and spills for easy cleaning.
Easy clean enamel cavities featuring a special antacid lining to help reduce cooking grease adherence.
Cast iron pan stands described as heavy duty for maximum stability and strength.
Five gas burners including rapid, semi rapid, ultra rapid (UR) and auxiliary zones up to 3.50 kW.
Gas safety valves cutting off gas if the flame is extinguished for greater safety.
Automatic electronic ignition on the hob for quick burner lighting.
Touch display timer for easy and intuitive timer setting with a single touch and start/stop cooking time.
Multilevel cooking with several shelf positions to allow maximum flexibility of use.
Multilevel halogen light and internal lighting on different levels for excellent visibility.
Triple glazed doors with thermo–reflective glass for an isothermic cavity and cold door surface.
Tangential cooling system with airflow from the door to the splashback for safe surface temperatures.
Full glass inner doors with removable inner glass for a flat, easy–to–clean surface.
Storage compartment with door providing more space for accessories or cooking utensils.
Adjustable height feet allowing the cooker top to be flushed with the working area.
Classic stainless steel design with Smeg Classic control knobs, brushed stainless steel handle and embossed logo.
Compatible accessories such as AirFry, pizza stone, BBQ plate, telescopic guides, trays and child lock (optional).

Technical Specifications

Model	CX92GM
Cooker size	90x60 cm
N. of cavities with energy label	2
Cavity heat source	Electric
Hob type	Gas
Type of main oven	Thermo–ventilated
Type of second oven	Static
Cleaning system main oven	Vapor Clean
EAN code	8017709341381
Energy efficiency class (main)	A
Energy efficiency class (second cavity)	A
Design	Standard
Series	Concert
Aesthetics	Classic
Colour	Stainless steel
Command panel finish	Stainless steel
Hob colour	Stainless steel
Logo	Embossed, position: facia below the oven
Upstand	Yes
Type of control setting	Control knobs
Control knobs	Smeg Classic, stainless steel, 8 controls
Serigraphy colour	Black
Display	Touch
Door	Full glass, flap down opening, 3 glasses with 1 thermo–reflective (each cavity)
Handle	Smeg Classic, brushed stainless steel
Storage compartment	Door
Feet	Black, adjustable height
No. of cooking functions (main)	6
Main oven traditional functions	Static, Fan assisted, Circulaire, ECO, Large grill, Fan assisted base
Cleaning functions (main)	Vapor Clean
Cooking functions cavity 2	4 – Static, Small grill, Large grill, Bottom element + Upper element / Bottom
Total no. of cook zones	5
Front left burner	Gas – Rapid – 3.00 kW
Rear left burner	Gas – Semi Rapid – 1.80 kW
Central burner	Gas – UR – 3.50 kW
Rear right burner	Gas – Semi Rapid – 1.80 kW
Front right burner	Gas – AUX – 1.00 kW
Type of gas burners	Standard
Automatic electronic ignition	Yes
Gas safety valves	Yes
Burner caps	Matte black enamelled
Main oven net volume	70 litres
Main oven gross volume	79 l
Main cavity material	Easy clean enamel
Main oven shelf positions	5 – metal racks
Main oven light	1 x Halogen, 40 W, light on when door is open
Main oven fan number	1
Main oven usable space (HxWxD)	360x460x425 mm
Main oven temperature control	Electro–mechanical
Main oven lower heating element power	1200 W
Main oven upper heating element power	1000 W
Main oven grill element	1700 W – electric grill
Circular heating element power	2000 W
Main oven timer	Yes, with cooking time start and stop, end of cooking acoustic alarm
Main oven temperature range	Minimum 50 °C – Maximum 260 °C
Second oven net volume	35 litres
Second oven gross volume	36 l
Second cavity material	Easy clean enamel
Second oven shelf positions	4 – metal racks
Second oven light	1 x Incandescent, 25 W
Second oven usable space (HxWxD)	311x206x418 mm
Second oven temperature control	Electro–mechanical
Second oven lower heating element power	700 W
Second oven upper heating element power	600 W
Second oven grill element power	1300 W – Large grill 1900 W – electric grill
Second oven temperature range	Minimum 50 °C – Maximum 245 °C
Safety thermostat	Yes (both cavities)
Cooling system	Tangential cooling with air cooling system
Cold door	External door glass is cold during any function
Isothermic cavity	Yes
Max power draw	4800 W
Current	21 A
Voltage	220–240 V
Voltage 2	380–415 V
Type of electric cable	Yes, Single phase
Additional connection modalities	Yes, Double and Three Phase
Frequency	50/60 Hz
Terminal block	5 poles
Power supply cable length	120 cm
Accessories included for main oven & hob	Chrome shelf with back and side stop (1), 20mm deep tray (1), 40mm deep tray (1), Grill mesh (1)
Accessories included for secondary oven	Chrome shelf with back and side stop (1), Wide baking tray (1), Grill mesh (1)

Additional Details and Usage

Gas Hob Benefits

Gas provides constant control of the heat source, with an immediate change in temperature. Equipped with a thermocouple, the gas supply is cut off if the flame is extinguished for greater safety.

Vapor Clean Function

The Vapor Clean function is an assisted steam clean programme designed to help loosen food residue and spills inside the oven for easy cleaning. Steam softens deposits on the enamel surface, making them easier to wipe away.

Circulaire and Multilevel Cooking

Circulaire combines the fan with a circular heating element to provide hot air cooking. It offers no preheat when cook time is more than 20 minutes, no flavour transfer when cooking different foods at the same time, less energy use and shorter cook times. Several cooking levels in the cavity allow multilevel cooking for maximum flexibility.

Grill and Base Functions

Upper and lower elements provide a traditional cooking method suited to roasts, fruit cakes and bread. The lower heating element only is ideal for foods needing extra base temperature without browning, such as pastry dishes and pizza, and for slow cooking stews and casseroles. The grill functions give excellent results for meat, sausages and bacon, with half grill focusing heat at the centre for smaller quantities.

Touch Control and Timer

The touch timer display guarantees simple functionality, displaying the time, programmed cooking and minute minder. Easy and intuitive timer setting with a single touch supports start and stop cooking times and an end of cooking acoustic alarm.

Lighting and Visibility

Multilevel halogen lighting and side lights (where present) increase visibility inside the oven. The light switches on when the door is opened in the main cavity, helping you monitor dishes without removing trays.

Door and Cleaning Convenience

The all glass inner door forms a single flat surface that is simple to keep clean. Inner door glass can be removed with a few quick movements for more thorough cleaning. Easy clean enamel with antacid lining reduces grease adhesion inside both cavities.

Optional Accessories and Cooking Styles

AirFry rack (AIRFRY) / AirFry tray (AIRFRY2) – Ideal for recreating traditional frying in the oven with fewer calories and less fat, for dishes such as French fries, fried vegetables and fish, ensuring browning and crispiness.
BBQ double sided plate – Suitable for succulent, crispy dishes with the taste of grilled cooking; ribbed side for meats and cheeses, smooth side for fish, seafood and vegetables.
Refractory pizza stone (STONE) – For pizzas with results similar to a wood–fired oven, and for bread, focaccias, pies, flans and biscuits.
Telescopic guides GTP/GTT – Partially or totally extractable guides (1 level) in polished stainless steel AISI 430 for easier tray handling.
Child lock (SFLK1) – Locking accessory.
Additional trays and grill plates – Cast iron grill plate, enamelled and Teflon–coated trays, pizza shovel and silicone mould set are available.

Frequently Asked Questions

How many ovens does the Smeg CX92GM have and what are their types?

This cooker has two electric cavities with energy labels. The main oven is thermo–ventilated, offering fan and Circulaire functions, while the second oven is static, providing traditional cooking with static, grill and bottom heating options.

What cleaning features are included?

The main oven has a Vapor Clean function, using steam to loosen food residue and spills for easier cleaning. Both cavities feature easy clean enamel with a special antacid lining to help reduce grease adhesion, and the full glass inner doors and removable inner glass simplify cleaning.

What safety features does this cooker offer?

Safety features include gas safety valves that cut off the gas if the flame is extinguished, a safety thermostat in both ovens, a tangential air cooling system, an isothermic cavity and triple glazed cold doors to avoid the risk of burns. The optional SFLK1 child lock accessory is also compatible.

What is the total hob configuration and power?

The gas hob has five zones: front left rapid 3.00 kW, rear left semi rapid 1.80 kW, central ultra rapid (UR) 3.50 kW, rear right semi rapid 1.80 kW and front right auxiliary 1.00 kW. Burners are standard type with matte black enamelled caps and automatic electronic ignition.

What are the oven capacities and temperature ranges?

The main oven has a net volume of 70 litres (gross 79 l) and operates between 50 °C and 260 °C. The second oven has a net volume of 35 litres (gross 36 l) with a temperature range from 50 °C to 245 °C.

What accessories are included and what optional ones are available?

Included accessories are a chrome shelf with back and side stop, 20mm and 40mm deep trays and a grill mesh for the main oven, plus a chrome shelf with back and side stop, wide baking tray and grill mesh for the secondary oven. Optional accessories include AirFry racks and trays, BBQ plate, cast iron grill plate, enamelled and Teflon trays, telescopic guides, height kits, splash back, pizza shovel, child lock, silicone moulds and a refractory pizza stone.
