The SMEG KDD90CNE2 is a fully integrated 90 cm downdraft cooker hood in black glass with a universal aesthetic. It offers ducted-out or recirculation extraction with perimeter extraction and touch controls. With four speeds including an intensive setting, LED lighting and an A class energy rating, it is designed to efficiently extract cooking vapours while integrating discreetly into the kitchen worktop.

Key Features

Downdraft cooker hood design – 90 cm fully integrated hood that rises from the worktop.
Flexible extraction – suitable for ducted out operation or re–circulation.
Perimeter extraction – perimeter extraction panels designed to aid noise reduction.
Touch control panel – easy to use electronic touch controls with digital display.
Four speeds plus intensive – 4 speed levels including an intensive/turbo setting for extra fast extraction.
24 hour air filter function – refreshes the air for about 10 minutes every hour over 24 hours at minimum speed.
Delay function / automatic switch–off – runs for a pre–set time after cooking then switches off automatically.
LED lighting – 1 × 5 W LED with 4000 K white light to illuminate the cooking area.
Dimmer mode – adjustable LED light intensity.
Aluminium anti–grease filters – 2 filters with indicator light to advise when filters need changing.
High extraction performance – intensive extraction rate up to 720 m³/h, free outlet maximum capacity 740 m³/h.
Energy efficiency class A – annual energy consumption 57 kWh/year, Fluid Dynamic Efficiency class A.
Integrated sliding door – sliding door feature for the downdraft body.
Optional remote motor and control – compatible with KITRBDD remote blower kit and RCKF2 remote control.
Alternative colour options – also available in White and Silver Glass.

Technical Specifications

Product family	Hood
Hood type	Downdraft Cooker Hoods
Design	Fully integrated
Extraction	Ducted out or re–circulation possible
Electronic control	Yes
Perimeter extraction	Yes
Material	Painted material
EAN code	8017709346126
Hood width	90 cm
Aesthetics	Universal
Colour	Black
Finishing	Glass
Glass type	Black
Serigraphy colour	Silver
Logo	Silk screen
Control setting	Touch control
Display	Digital
LED colour	White
Number of speeds	4
Intensive speed	Yes (Intensive/turbo setting)
24 h air filter function	Yes
Other functions	Delay_function, Time–setting options
Remote motor	KITRBDD – Kit Optional
Number of lights	1
Light type	LED
Light power	5 W
Light colour temperature scale	4000 K
Dimmer mode	Yes
Free outlet maximum capacity	740 m³/h
Motor power	250 W
Number of filters	2
Anti–grease filters	Aluminium
Filter replacement indicator	Yes (warning light to advise when filters need changing)
Vent outlet	150 mm
Remote control	Optional
Sliding door	Yes
Tube reduction	Yes
Annual Efficiency Consumption (AEChood)	57 kWh/year
Energy efficiency class (EEC)	A
Fluid Dynamic Efficiency (FDE)	29,30
Fluid Dynamic Efficiency class (FDEC)	A
Lighting Efficiency (LE)	40 lux/W
Lighting Efficiency Class (LEC)	A
Grease Filtering Efficiency (GFE)	65,1 %
Grease Filtering Efficiency Class (GFEC)	D
Air flow at minimum speed (Qmin)	200 m³/h
Maximum extraction rate	350 m³/h
Intensive extraction rate	720 m³/h
Airborne acoustical A–weighted sound power emission at minimum speed (SPEmin)	43 dBA
Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)	53 dBA
Airborne acoustical A–weighted sound power emission at boost speed (SPEboost)	68 dBA
Time increase factor (F)	0,9
Energy Efficiency Index per first cavity	53,1
Measured air flow rate at best efficiency point (Qbep)	398 m³/h
Measured air pressure at best efficiency point (Qbep)	429 Pa
Measured electric power input at best efficiency point (Wbep)	162 W
Normal power of the light system (Wl)	5 W
Average illumination of the light on the cooking surface (Emiddle)	200 lux
Sound power level at highest setting (Lwa)	49 dBA
Extraction rate IEC 61591 / Noise level IEC 60704–2–13	Speed 1: 200 m³/h – 43 dBA Speed 2: 280 m³/h – 49 dBA Speed 3: 350 m³/h – 53 dBA Speed 4: 440 m³/h – 57 dBA Intensive speed: 720 m³/h – 68 dBA
Nominal power	255 W
Voltage	220–240 V
Frequency (Hz)	50–60 Hz
Power supply cable length	1500 mm
Plug	(F;E) Schuko
Alternative colours available	White, Silver Glass

Additional Details & Usage

Controls and display

The hood uses touch controls, allowing the appliance to be programmed at the touch of a button. A digital electronic display provides a visual reminder of the options selected.

Functions and programmes

Four speed levels including an intensive/turbo setting when extra fast extraction is required.
24 h function refreshes the air for approximately 10 minutes every hour over a 24 hour period at minimum speed and with an imperceptible noise level.
Delay / switch–off automatically setting runs after the end of cooking for a pre–set time and then switches off automatically.
Time–setting options are available via the touch controls.

Filtration and maintenance

Model has filters to help remove grease from the steam emanating from the pans during cooking.
Warning light advises when filters need changing (filter replacement indicator).
Compatible charcoal filter KITFCDD (Down Draft Kit, 1 piece, dishwasher safe) for recirculation use.

Lighting

The cooker hood features LED lighting to illuminate the cooking area or add to the ambience of the kitchen. Lighting efficiency is rated at 40 lux/W with Lighting Efficiency Class A.

Accessories and options

KITFCDD – charcoal filter for hood Down Draft Kit, 1 piece, dishwasher safe.
KITRBDD – kit remote blower for downdraft hood.
RCKF2 – remote control.
Remote control functionality is optional.

Frequently Asked Questions

Can this hood be used in recirculation as well as ducted mode?

Yes. The extraction system allows for ducted out or re–circulation operation. For recirculation, a compatible charcoal filter such as KITFCDD can be used.

How many speed settings does the SMEG KDD90CNE2 have?

The hood offers four speeds plus an intensive speed. Extraction rates range from 200 m³/h at speed 1 up to 720 m³/h on intensive.

What is the energy rating of this downdraft hood?

The energy efficiency class is A, with an annual energy consumption (AEChood) of 57 kWh/year and a Fluid Dynamic Efficiency class of A.

Does the hood have a filter change reminder?

Yes. A warning light acts as a filter replacement indicator to advise when the aluminium anti–grease filters need changing.

Is a remote control available?

A remote control is optional. The hood is compatible with the RCKF2 remote control and the KITRBDD remote blower kit.
