The SMEG KD61XE3 is a 60 cm stainless steel chimney cooker hood from the Universal aesthetic family, designed for ducted or recirculating extraction. With three button-controlled speeds and a maximum extraction rate of 600 m³/h, it helps remove grease and steam from cooking. LED lighting at 4000 K illuminates the hob area, while aluminium anti-grease filters support effective filtration. It offers a C energy efficiency class and flexible installation distances above gas or electric hobs.

Key Features

Product family & type: Chimney cooker hood from the Universal aesthetic range.
Hood width: 60 cm stainless steel design with brushed finishing and embossed logo.
Extraction options: Ducted out or re-circulation possible for flexible installation.
Control setting: Button controls with 3 speeds for different cooking needs.
Maximum extraction rate: Up to 600 m³/h, with free outlet maximum capacity of 620 m³/h.
LED lighting: Two 4 W LED lights (8 W total) at 4000 K to illuminate the cooking surface.
Anti-grease filters: Two aluminium filters to help remove grease from steam.
Noise levels: From 45 dBA at minimum speed to 63 dBA at maximum speed.
Energy performance: Annual efficiency consumption 79 kWh/year, energy efficiency class C.
Lighting efficiency: 17 lux/W with lighting efficiency class C.
Grease filtering efficiency: 75.1 % with grease filtering efficiency class C.
Minimum installation distances: 650 mm from gas hobs and 500 mm from electric hobs.
Vent connection: 150 mm vent outlet with tube reduction included.
Electrical connection: 220–240 V, 50–60 Hz, nominal power 168 W, motor power 160 W.
Compatible accessory: KITFC152 charcoal filters round kit (2 pieces) for recirculation use.

Technical Specifications

Product code	KD61XE3
Product family	Hood
Hood type	Chimney Cooker Hoods
Design	Chimney
Aesthetics	Universal
Material	Stainless steel, brushed type of steel
Colour / finishing	Stainless steel, brushed, embossed logo
Hood width	60 cm
Extraction	Ducted out or re-circulation possible
Control setting	Buttons, 3 speeds
Number of lights	2
Light type / power	LED, 4 W each (Normal power of the light system 8 W)
Light colour temperature	4000 K
Free outlet maximum capacity	620 m³/h
Motor power	160 W
Number of filters	2 aluminium anti-grease filters
Vent outlet	150 mm (tube reduction included)
Minimum distance from gas hob	650 mm
Minimum distance from electric hob	500 mm
Maximum extraction rate	600 m³/h
Air flow at minimum speed (Qmin)	260 m³/h
Extraction rate IEC 61591 – Speed 1	260 m³/h, 45 dBA
Extraction rate IEC 61591 – Speed 2	390 m³/h, 54 dBA
Extraction rate IEC 61591 – Speed 3	600 m³/h, 63 dBA
Airborne acoustical A–weighted sound power emission at minimum speed (SPEmin)	45 dBA
Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)	63 dBA
Sound power level at highest setting (Lwa)	63 dBA
Annual efficiency consumption (AEChood)	79 kWh/year
Energy efficiency class (EEC)	C
Fluid Dynamic Efficiency (FDE)	18.20
Fluid Dynamic Efficiency class (FDEC)	C
Lighting Efficiency (LE)	17 lux/W
Lighting Efficiency Class (LEC)	C
Grease Filtering Efficiency (GFE)	75.1 %
Grease Filtering Efficiency Class (GFEC)	C
Time increase factor (F)	1.3
Energy Efficiency Index per first cavity	75.6
Measured air flow rate at best efficiency point (Qbep)	338 m³/h
Measured air pressure at best efficiency point (Qbep)	300 Pa
Measured electric power input at best efficiency point (Wbep)	155 W
Average illumination of the light on the cooking surface (Emiddle)	133 lux
Nominal power	168 W
Voltage	220–240 V
Frequency	50–60 Hz
Power supply cable length	1500 mm

Additional Details and Usage

The hood can operate either ducted to the outside or in recirculation mode using suitable charcoal filters. Tube reduction is included for connection to the vent outlet.

Three speeds are selected using button controls, allowing adjustment of extraction rate and noise level to suit different cooking activities.

The aluminium anti-grease filters are designed to help remove grease from the steam produced during cooking. The integrated LED lighting illuminates the cooking area and can also contribute to the ambience of the kitchen.

For safe installation, the hood should be positioned at least 650 mm above a gas hob and 500 mm above an electric hob.

Frequently Asked Questions

Can this cooker hood be used in recirculation mode?

Yes. The extraction system allows for ducted out or re-circulation operation. For recirculation, compatible charcoal filters such as the KITFC152 charcoal filters round kit (2 pieces) can be used.

What is the maximum extraction rate of the SMEG KD61XE3?

The maximum extraction rate is 600 m³/h, with a free outlet maximum capacity of 620 m³/h.

How noisy is the hood during operation?

At minimum speed, the airborne acoustical A–weighted sound power emission is 45 dBA. At maximum speed, it reaches 63 dBA, which is also the sound power level at the highest setting.

What type of filters are included?

The hood comes with two aluminium anti-grease filters. These filters help remove grease from the steam emitted from pans during cooking.

What are the installation height requirements above the hob?

The minimum distance from a gas hob is 650 mm, and the minimum distance from an electric hob is 500 mm.
