The SMEG CVI338LX3 is a built-in wine cooler designed for a 82–87 cm niche, ideal for storing up to 38 bottles of 0,75 l wine. It features two adjustable temperature zones with independent cooling systems, automatic defrost and fan–assisted cooling for even temperature distribution. With wooden shelves, LED internal lighting, touch controls and a low vibration compressor, it provides carefully controlled conditions for wine storage in a fitted kitchen setting.

Key Features

Built-in design for a 82–87 cm niche, with standard left hinge and door opening with handle.
Generous capacity with max capacity of 38 bottles (0,75 l) and total volume of 114 l.
Dual temperature zones with 2 adjustable temperature zones and 2 independent cooling systems.
Wide temperature range of 5–20 °C with electronic temperature control.
Fan assisted cooling (ventilated) for even cold air distribution in the compartment.
Automatic defrost system eliminating the need for manual defrosting.
Low vibration compressor to help provide stable storage conditions.
LED internal lighting with lighting forced ON available for a maximum period.
Anti-UV door glass to help protect contents from light.
Touch controls with internal control setting and LED display.
Temperature and door alarms including temperature alarm and door open alarm.
Control lock function to help prevent unwanted changes to settings.
Wooden shelving with 2 fixed shelves and 3 removable shelves.
Telescopic guide rails for removable shelves for easier access.
Activated charcoal air filter within the compartment.
Integrated heating element and metal panel on the back of the fridge.
Adjustable feet with 2 front and 2 rear feet to aid installation.
Energy efficiency class G with annual energy consumption of 140 kWh/year.
Quiet operation with noise level of 38 dB(A) re 1 pW and noise emission class C.
Schuko plug with 180 cm power supply cable for standard connection.

Technical Specifications

Product family	Wine Cooler
Model	CVI338LX3
Installation	Built-in
Built-in niche	82–87 cm
Defrost	Automatic
Cooling type	Fan assisted (ventilated)
Hinge type	Standard
Hinge position	Left
Door opening type	With handle
Number of fixed shelves	2
Number of removable shelves	3
Shelves material	Wood
Removable shelves on telescopic guide rails	Yes
Type of internal light	LED
Lighting forced ON	In a maximum period
Air filter	Activated charcoal filter
Control setting	Touch control
Controls position	Internal, in the compartment
Display type	LED
Functions display	Temperature alarm, Temperature value
Power on lamp	Yes
Control lock	Yes
Fan forced ON	Yes
Temperature alarm	Yes
Door open alarm	Yes
Adjustable temperature zones	2
Independent cooling systems	2
Number of door glasses	2
Compressor type	Low vibration compressor
Refrigerant gas type	R600a
Refrigerant quantity	20 g
Temperature range	5–20 °C
Type of temperature control	Electronic
Anti-UV door glass	Yes
Integrated heating element	Yes
Number of compressors	1
Foam agent	HFO
Metal panel on the back of the fridge	Metal
Adjustable feet	2 Front + 2 Rear
Max capacity (bottles 0,75 lt)	38
Annual energy consumption	140 kWh/year
Energy efficiency class	G
Airborne acoustical noise emission class	C
Total volume	114 l
Sum of volumes of chill and unfrozen compartments	114 l
Climatic class	SN, N, ST
EEI	165 %
Noise level	38 dB(A) re 1 pW
Nominal power	40 W
Current	0,4 A
Voltage	220–240 V
Frequency	50 Hz
Power supply cable length	180 cm
Plug	(F;E) Schuko

Additional Details and Operation

The wine cooler uses fan assisted, ventilated cooling for forced distribution of cold air, providing even temperature distribution within the compartment. An automatic defrost system operates at regular intervals, removing the need for manual defrosting.

Internal touch controls and an LED display show the selected functions, temperature value and temperature alarms. A power on lamp and control lock are included. The unit features an activated charcoal air filter and an integrated heating element, along with anti–UV door glass and a metal panel on the back of the fridge.

LED interior lighting provides illumination inside the appliance and can be forced ON for a maximum period. Adjustable feet (2 front and 2 rear) assist with level installation in a built-in niche.

Frequently Asked Questions

How many bottles can the SMEG CVI338LX3 hold?

The maximum capacity is 38 bottles of 0,75 lt, with a total internal volume of 114 l.

What is the temperature range of this wine cooler?

The temperature range is 5–20 °C, managed by electronic temperature control.

Does it have separate temperature zones?

Yes, it has 2 adjustable temperature zones supported by 2 independent cooling systems.

Is the defrosting process manual or automatic?

The appliance features an automatic defrost system that defrosts at regular intervals, removing the need for manual defrosting.

What type of lighting is used inside the wine cooler?

The wine cooler uses LED interior lighting, which is described as a more energy efficient and long lasting way of illuminating the interior.

What alarms and safety features are included?

It includes a temperature alarm, door open alarm, power on lamp and a control lock function.
