The SMEG CVI329X3 is a built–in wine cooler designed for a 60 cm niche, ideal for integrated kitchen installations. It offers fan assisted cooling, automatic defrost and dual adjustable temperature zones for flexible wine storage. With capacity for up to 29 bottles (0,75 lt), wooden shelves, low vibration compressor and LED interior lighting, it combines practical features with touch control operation and electronic temperature control.

Key Features

Built–in wine cooler for 60 cm niche – designed for integrated installation with variable right–hand hinge and reversible door.
Fan assisted cooling – ventilated system for forced distribution of cold air and even temperature in the compartment.
Dual adjustable temperature zones – 2 zones with electronic temperature control and a range of 5–20 °C.
29 bottle capacity – maximum capacity for 0,75 lt bottles with a total volume of 79 l.
Wooden shelves with telescopic guide rails – 1 fixed shelf and 2 removable shelves for organised bottle storage.
LED interior lighting – 2 LED lights for efficient, long–lasting illumination of the compartment.
Touch controls with LED display – internal touch control panel and LED display showing temperature values and alarms.
Temperature and door open alarms – temperature alarm and door open alarm for added protection of stored wine.
Low vibration compressor – 1 independent cooling system with low vibration compressor and refrigerant gas R600a.
Anti–UV door glass – 2 door glasses with anti–UV treatment to help protect wine from light.
Activated charcoal air filter – helps maintain air quality inside the compartment.
Control lock and power on lamp – lockable controls and a power on lamp for safe and clear operation.
Lighting and fan forced ON options – lighting forced ON for a maximum period and fan forced ON when required.
Automatic defrost system – automatically defrosts at regular intervals, eliminating the need to defrost manually.
Energy efficiency class G – annual energy consumption of 140 kWh/year and EEI 170 %.
Quiet operation – noise level of 38 dB(A) re 1 pW with airborne acoustical noise emission class C.
Push pull door opening – convenient door opening type with metal panel on the back of the fridge.

Technical Specifications

Product family	Wine Cooler
Model	CVI329X3
Installation	Built–in
Built–in niche	60 cm
Defrost	Automatic
Cooling type	Fan assisted (Ventilated)
Independent cooling systems	1
Hinge type / position	Variable hinge, right
Reversible door	Yes
Door opening type	With push pull system
Number of door glasses	2
Anti–UV door glass	Yes
Integrated heating element	Yes
Number of fixed shelves	1
Number of removable shelves	2
Shelves material	Wood
Removable shelves on telescopic guide rails	Yes
Type of internal light / number of lights	LED, 2 lights
Air filter	Activated charcoal filter
Control setting / controls	Touch control; internal, in the compartment
Display type	LED display
Functions display	Temperature alarm, Temperature value
Power on lamp	Yes
Control lock	Yes
Lighting forced ON	In a maximum period
Fan forced ON	Yes
Temperature alarm / door open alarm	Yes / Yes
Adjustable temperature zones	2
Number of compressors	1 (low vibration compressor)
Refrigerant gas type / quantity	R600a, 20 g
Foam agent	HFO
Metal panel on the back of the fridge	Metal
Temperature range	5–20 °C
Type of temperature control	Electronic
Max capacity (bottles 0,75 lt)	29
Total volume	79 l
Sum of volumes of chill and unfrozen compartments	79 l
Annual energy consumption	140 kWh/year
Energy efficiency class	G (EEI 170 %)
Climatic class	SN, N, ST
Noise level	38 dB(A) re 1 pW
Airborne acoustical noise emission class	C
Nominal power	40 W
Current	0,4 A
Voltage	220–240 V
Frequency	50 Hz
Power supply cable length	180 cm
Plug type	(F;E) Schuko

Additional Details and Functions

Touch controls allow the appliance to be programmed at the touch of a button, with an LED display showing the programmes, selected functions and remaining indications such as temperature values and alarms.

The automatic defrost system works by automatically defrosting at regular intervals, eliminating the need to defrost altogether. Ventilated fan assisted cooling provides forced distribution of cold air in the refrigerator compartment for even temperature distribution.

LED interior lighting offers an energy efficient and long lasting way of illuminating the interior of the appliance, while the activated charcoal filter helps maintain air quality around stored bottles.

Frequently Asked Questions

How many bottles can the SMEG CVI329X3 wine cooler hold?

The maximum capacity is 29 bottles of 0,75 lt. The total internal volume of the cooler is 79 l.

What is the temperature range and how is it controlled?

The temperature range is 5–20 °C. Temperature is managed by electronic temperature control with 2 adjustable temperature zones and values shown on the LED display.

Is the door reversible and what type of glass does it use?

Yes, the door is reversible with a variable hinge positioned on the right. It has 2 door glasses featuring anti–UV door glass.

Does the wine cooler have alarms for safety and convenience?

Yes. It includes a temperature alarm, door open alarm, power on lamp and control lock. Temperature values and alarms are displayed on the LED display.

What is the energy efficiency class and noise level?

The energy efficiency class is G with an annual energy consumption of 140 kWh/year and EEI of 170 %. The noise level is 38 dB(A) re 1 pW with airborne acoustical noise emission class C.

What type of cooling and defrost systems does it use?

It uses fan assisted, ventilated cooling with 1 independent cooling system and a low vibration compressor. The appliance has an automatic defrost system that defrosts at regular intervals, removing the need for manual defrosting.
