The SMEG CVI621NR3 is a built–in wine cooler designed for a 45 cm niche, offering fan assisted cooling and automatic defrost. With capacity for up to 21 bottles (0.75 l) on wooden shelves, it uses a low vibration compressor and electronic temperature control between 5–20 °C. LED lighting, touch controls and an activated charcoal air filter help provide convenient storage and easy operation for wine storage at home.

Key Features

Built–in 45 cm niche design for seamless installation as a built–in wine cooler.
Max capacity 21 bottles (0.75 l) with a total volume of 56 l for wine storage.
Fan assisted cooling with ventilated cold air distribution in the compartment.
Automatic defrost system that defrosts at regular intervals, removing the need for manual defrosting.
Electronic temperature control with an adjustable range between 5–20 °C and LED temperature display.
Low vibration compressor with refrigerant gas type R600a and 1 independent cooling system.
Wooden shelving including 1 fixed shelf and 2 removable shelves on telescopic guide rails.
LED interior lighting with the option for lighting forced ON for a maximum period.
Right–hand standard hinge with reversible door and push pull door opening system.
Anti–UV double glazed door glass to help protect contents from light.
Activated charcoal air filter in the compartment.
Internal touch controls with control lock and LED display for functions.
Temperature and door open alarms plus temperature value indication and power on lamp.
Energy efficiency class F with annual energy consumption of 100 kWh/year.
Quiet operation with a noise level of 36 dB(A) re 1 pW and airborne acoustical noise emission class C.

Technical Specifications

Product family	Wine Cooler
Model	CVI621NR3
Installation	Built–in
Built–in niche	45 cm
Defrost	Automatic
Cooling type	Fan assisted
Hinge type / position	Standard – Right
Reversible door	Yes
Door opening type	With push pull system
Number of fixed shelves	1
Number of removable shelves	2
Shelves material	Wood
Removable shelves on telescopic guide rails	Yes
Type of internal light	LED
Air filter	Activated charcoal filter
Control setting	Touch control
Controls	Internal, in the compartment
Display	LED
Functions display	Temperature alarm, Temperature value
Power on lamp	Yes
Control lock	Yes
Lighting forced ON	In a maximum period
Fan forced ON	Yes
Temperature alarm	Yes
Door open alarm	Yes
Adjustable temperature zones	1
Independent cooling systems	1
Number of door glasses	2
Number of compressors	1
Compressor type	Low vibration compressor
Refrigerant gas type	R600a
Temperature range	5–20 °C
Type of temperature control	Electronic
Anti–UV door glass	Yes
Integrated heating element	Yes
Refrigerant quantity	20 g
Foam agent	HFO
Metal panel on the back of the fridge	Metal
Max capacity (bottles 0.75 l)	21
Annual energy consumption	100 kWh/year
Energy efficiency class	F
Airborne acoustical noise emission class	C
Total volume	56 l
Sum of the volumes of the chill and unfrozen compartments	56 l
Climatic class	SN, N, ST
EEI	124 %
Noise level	36 dB(A) re 1 pW
Nominal power	40 W
Current	0.4 A
Voltage	220–240 V
Frequency	50 Hz
Power supply cable length	180 cm
Plug type	(F;E) Schuko

Additional Details and Functions

The appliance uses ventilated cooling, providing forced distribution of cold air in the refrigerator compartment to allow even temperature distribution. The automatic defrost system operates at regular intervals, eliminating the need for manual defrosting.

Touch controls allow the appliance to be programmed at the touch of a button. The LED display shows programmes, functions, options selected and temperature values, as well as temperature alarms. LED interior lighting offers an energy efficient and long lasting way of illuminating the interior.

The built–in configuration is designed for a suitable niche, and the reversible door with push pull system provides flexibility in door opening direction. An integrated heating element and anti–UV door glass are included as part of the technical design.

Frequently Asked Questions

What is the bottle capacity of the SMEG CVI621NR3 wine cooler?

The maximum capacity is 21 bottles of 0.75 l, with a total internal volume of 56 l.

What temperature range can this wine cooler maintain?

The temperature range is 5–20 °C, managed by electronic temperature control.

Is the door reversible?

Yes. The cooler has a standard right hinge as supplied, and the door is reversible.

Does it have alarms for temperature and open door?

Yes. It features a temperature alarm, temperature value display and a door open alarm, as well as a power on lamp.

What type of lighting is used inside the wine cooler?

The interior uses LED lighting, with the option to keep the lighting forced ON for a maximum period.

What is the energy efficiency class and annual consumption?

The energy efficiency class is F, with an annual energy consumption of 100 kWh/year and an EEI of 124 %.
