The Smeg CX103GMBL is a 100x60 cm Concert cooker combining a gas hob with three thermo–ventilated electric ovens. Designed with Classic gloss black aesthetics, enamelled metal control panel and Smeg Classic stainless steel knobs, it offers Circulaire cooking, multilevel halogen lighting and Ever Clean enamel cavities for easier cleaning. With energy efficiency class A for the main oven and B for the second cavity, it suits users seeking flexible multilevel cooking and electric oven performance with gas hob control.

Key Features

Cooker size 100x60 cm for generous hob space and multiple oven cavities.
Three electric ovens with thermo–ventilated main and second ovens plus a third oven.
Gas hob with 5 cooking zones including dual 4.20 kW, Rapid and Semi Rapid burners.
Circulaire cooking in main and auxiliary ovens for ventilated circular heat flow.
Energy efficiency class A for the main cavity and class B for the second cavity.
Easy clean enamel cavities with antacid lining to help reduce dirt adherence.
Heavy duty cast iron pan stands for maximum stability and strength on the gas hob.
Touch display timer for intuitive cooking time setting with start and stop functions.
Multilevel cooking with up to 9 shelf positions in the second cavity.
Multilevel halogen lighting providing excellent visibility inside the cavities.
Triple glazed doors on selected cavities and double glazed on the second oven.
Tangential cooling system with airflow from door to splashback for safe surface temperatures.
Gas safety valves and thermocouple cutting off gas if the flame is extinguished.
Cold door exterior during functions to help avoid risk of burns.
Removable inner glass doors and tilting grill for easier cleaning access.
Chrome shelves and deep trays included across main, secondary and third ovens.
Compatible accessories such as AirFry racks and trays, BBQ plates, pizza shovel and child lock.
Electro–mechanical temperature control with minimum 50 °C and up to 260 °C depending on cavity.
Max power draw 8600 W with single, double or three phase electrical connection options.

Technical Specifications

Model	CX103GMBL
Series	Concert
Aesthetics	Classic
Cooker size	100x60 cm
Number of cavities with energy label	2
Cavity heat source	Electric
Hob type	Gas
Type of main oven	Thermo–ventilated
Type of second oven	Thermo–ventilated
EAN code	8017709336622
Energy efficiency class (main cavity)	A
Energy efficiency class, second cavity	B
Design	Standard
Command panel finish	Enamelled metal
Colour / Finishing	Black, Gloss Black
Hob colour	Black enamel
Pan stands	Cast Iron, heavy duty
Controls type	Control knobs, Smeg Classic, stainless steel, 8 controls, silver serigraphy
Display	Touch timer display / DigiScreen
Door	With frame, black glass
Handle	Smeg Classic, brushed stainless steel
Feet / Plinth	Feet none; Plinth Black
Total no. of cook zones	5
Left centre burner	Gas – 2UR (dual) – 4.20 kW
Rear centre burner	Gas – Semi Rapid – 1.80 kW
Front centre burner	Gas – AUX – 1.00 kW
Rear right burner	Gas – Rapid – 2.90 kW
Front right burner	Gas – Semi Rapid – 1.80 kW
Type of gas burners	Standard
Automatic electronic ignition	Yes
Gas safety valves	Yes
Burner caps	Matte black enamelled
Main oven net volume	61 litres
Main oven gross volume	70 l
Main cavity material	Easy clean enamel with antacid lining
Main oven shelf positions	4, metal racks
Main oven light	Halogen, 40 W
Main oven door opening	Side opening
Main oven door glasses	3 total, 1 thermo–reflective; full glass inner, removable door and inner door
Main oven safety and cooling	Safety thermostat; tangential cooling system
Main oven usable cavity (HxWxD)	316x460x412 mm
Main oven heating element	Circular heating element 2000 W
Main oven temperature control	Electro–mechanical, 50 °C to 245 °C
Second oven net volume	84 litres
Second oven gross volume	94 l
Second cavity material	Easy clean enamel
Second oven shelf positions	9, metal racks
Second oven light	Halogen, 40 W
Second oven door opening	Side opening
Second oven door glasses	2 total, 1 thermo–reflective; full glass inner; removable door
Second oven safety and cooling	Safety thermostat; tangential cooling system
Second oven usable cavity (HxWxD)	605x275x370 mm
Second oven heating element	Circular heating element 2500 W
Second oven temperature range	50 °C to 245 °C
Third oven net volume	35 l
Third oven gross volume	41 l
Third cavity material	Easy clean enamel
Third oven shelf positions	2, metal racks
Third oven light	Halogen, 40 W
Third oven door opening	Flap down
Third oven door glasses	3 total, 1 thermo–reflective; full glass inner; removable door and inner door
Third oven safety and cooling	Safety thermostat; tangential cooling system
Third oven usable cavity (HxWxD)	169x440x443 mm
Third oven grill power	Large electric grill 2700 W, tilting grill
Third oven temperature range	50 °C to 260 °C
Total no. of cooking functions (main)	4 traditional functions: Circulaire, Small grill, Large grill, Fan grill (large)
Cooking functions cavity 2	1 traditional function: Circulaire
Third oven functions	1 function: Full grill
Cooking time setting	Start and Stop, timer with end of cooking acoustic alarm
Accessories (main oven & hob)	Chrome shelf with back and side stop 1; 40 mm deep tray 1
Accessories (secondary oven)	Chrome shelf with back stop 3
Accessories (third oven)	Chrome shelf with back and side stop 1; 40 mm deep tray 1
Max power draw	8600 W
Current	38 A
Voltage	220–240 V; Voltage 2: 380–415 V
Type of electric cable	Yes, Single phase
Additional connection modalities	Yes, Double and Three Phase
Frequency	50/60 Hz
Terminal block	5 poles

Additional Details and Usage

Gas hob benefits

Gas provides constant control of the heat source with immediate temperature changes. Equipped with a thermocouple and gas safety valves, the gas supply is cut off if the flame is extinguished for greater safety. Heavy duty cast iron pan stands offer maximum stability and strength.

Ever Clean enamel

The enamel interior of the ovens has a special antacid lining (Ever Clean enamel) which helps keep the interior clean by reducing the amount of cooking grease and dirt adhering to the surface, allowing easier oven cleaning.

Circulaire and multilevel cooking

Circulaire combines the fan and circular heating element to provide hot air cooking without preheat if cook time is more than 20 minutes, with no flavour transfer when cooking different foods at the same time. Multiple fans and heating elements create an aerodynamic heat flow for homogeneous and quicker cooking. Several cooking levels (up to 9 in the second cavity) allow maximum flexibility and multilevel cooking.

Lighting and visibility

Internal halogen lighting and, where specified, side lights on different levels guarantee excellent visibility inside the oven. Full glass inner doors provide a single flat surface which is simple to keep clean.

Cooling and safety

The tangential cooling system with a fan circulates air from the door to the splashback to ensure safe surface temperatures. During any function, the external door glass remains cold, reducing the risk of burns. Safety thermostats are fitted to all cavities.

Cleaning features

Internal door glasses are easily removable for complete cleaning; the inner glass can be removed with a few quick movements. The tilting grill can be unhooked to move the heating element and clean the roof of the appliance in one step. Ever Clean enamel further helps reduce grease adherence.

Timer and controls

The touch control timer display enables easy and intuitive setting with a single touch, showing time, programmed cooking and minute minder. Cooking time can be managed with start and stop settings and an end of cooking acoustic alarm.

Compatible accessories

Air fryer rack AIRFRY and Air fryer tray AIRFRY2 for recreating traditional frying in the oven with fewer calories and less fat, ideal for French fries, fried vegetables and fish, ensuring browning and crispiness.
Double sided plate BBQ for succulent and crispy dishes with grilled taste: ribbed side for meats and cheeses, smooth side for fish, seafood and vegetables.
Cast iron grill plate BG6090–1 suitable for Concert cookers; enamelled trays BN620–1 (20 mm) and BN640 (40 mm); Teflon–coated tray BNP608T to be placed on the grid.
Telescopic guides GTP (partially extractable, 300 mm) and GTT (totally extractable, 433 mm) in polished stainless steel AISI 430 (1 level).
Splashback KIT90N9 (90 cm, black), height extension kit KITH93 (950 mm, suitable for TR93 cookers), pizza shovel PALPZ, child lock SFLK1.
SMOLD set of 7 silicone moulds usable from −60 °C to +230 °C, and WOKGHU cast–iron WOK support.

Additional benefits

Adjustable height allows the cooker top to be flushed with the working area thanks to adjustable feet (where fitted).
Isothermic cavity for high cooking performance at high energy efficiency.
Single turbine fan with circular heating element enabling cooking with rotating heat.
Optional AirFry basket, pizza stone, and BBQ accessories for lighter fried food, crispy pizza and barbecue–style cooking directly in the oven.

Frequently Asked Questions

How many ovens does the Smeg CX103GMBL have?

This cooker has three electric ovens: a thermo–ventilated main oven, a thermo–ventilated second oven, and a third oven with full grill function. Two cavities carry energy labels, with classes A and B respectively.

What cooking functions are available?

The main oven offers four traditional functions: Circulaire, Small grill, Large grill and Fan grill (large). The second cavity provides one traditional Circulaire function, while the third oven has one Full grill function with a large electric grill.

Is the oven easy to clean?

The cavities use Ever Clean enamel with a special antacid lining to help reduce grease and dirt adherence. Full glass inner doors and removable inner glass make cleaning easier, and the tilting grill allows access to the oven roof.

How safe is the gas hob?

The gas hob includes a thermocouple and gas safety valves that cut off the gas supply if the flame is extinguished. Heavy duty cast iron pan stands provide stable support for cookware.

What is the temperature range of the ovens?

All cavities use electro–mechanical temperature control. The main and second ovens operate from 50 °C to 245 °C, while the third oven with large grill operates from 50 °C to 260 °C.

Are special accessories like AirFry or BBQ available?

Compatible accessories include the AIRFRY rack, AIRFRY2 tray, double sided BBQ plate, pizza shovel, cast iron grill plate, enamelled and Teflon trays, telescopic guides, child lock and WOK support, among others.
