The Gaggenau GV251130 is a vacuuming drawer from the Minimalistic series, designed for flush, handleless integration in a 14 cm high niche. It offers a hygienic stainless steel vacuuming chamber with up to 99% vacuuming in the chamber and up to 90% outside the chamber. With touch key operation, three vacuuming and heat-sealing levels and included accessories, it supports sous-vide cooking, fast marinating, flavouring and vacuuming of containers and bottles.

Key Features

Integrable in 14 cm high niche for a seamless fit in compatible kitchen furniture.
Hygienic stainless steel vacuuming chamber with applicable height up to 95 mm.
3 vacuuming levels in the chamber providing up to max. 99% vacuuming.
3 vacuuming levels outside the chamber providing up to max. 90% vacuuming.
Automatic connection recognition for vacuuming outside the chamber.
Flush installation and handleless drawer with push-to-open function for a minimalistic look.
Vacuuming for sous-vide cooking to prepare food in vacuum-sealed bags.
Vacuuming for fast marinating and flavouring of foods.
Vacuuming of containers outside the chamber using compatible vacuuming equipment.
Vacuuming of liquids in bottles outside the chamber with adaptors and plugs.
Net volume 7 litres with maximum capacity load of 10 kg.
3 heat-sealing levels for different strengths of bag material.
Maximum vacuuming bag size of W 240 mm x L 350 mm.
Non-stick, removable sealing bar for easier handling.
Safety glass cover that opens automatically after vacuuming.
Raised vacuuming platform, 44 mm, deployable for flexible positioning.
Utility space in vacuuming chamber of W 210 mm x L 275 mm.
Membrane to avoid reflow of liquids during vacuuming outside the chamber.
Drying programme for vacuuming pump to support maintenance of performance.
Included accessories comprise vacuuming bags, platforms, adaptors, hose and bottle plugs.

Technical Specifications

Model	GV251130
Product type	Vacuuming drawer Gaggenau Minimalistic series
Front dimensions	60 x 14 cm
Niche integration	Integrable in 14 cm high niche; plan niche without back wall
Vacuuming chamber material	Hygienic stainless steel
Applicable chamber height	Up to 95 mm
Net volume	7 litres
Maximum load capacity	Max. 10 kg
Vacuum levels (in chamber)	3 levels, max. 99% vacuuming
Vacuum levels (outside chamber)	3 levels, max. 90% vacuuming
Maximum bag size	W 240 mm x L 350 mm
Utility space in chamber	W 210 mm x L 275 mm
Raised vacuuming platform	44 mm, deployable
Controls	Touch key operation; push-to-open function
Installation style	Flush installation; handleless drawer
Protrusion from cabinet front	21 mm from appliance front to furniture cabinet
Heat-sealing levels	3 levels for different strengths of bag material
Sealing bar	Non-stick coating, removable
Cover	Safety glass cover, opens automatically after vacuuming
Membrane function	Membrane for avoiding reflow of liquids during vacuuming outside the chamber
Drying programme	Drying programme for vacuuming pump
Included accessories	50 x vacuuming bag small; 50 x vacuuming bag big; 1 x raised vacuuming platform; 1 x adaptor for vacuuming outside the chamber; 1 x vacuuming hose; 1 x adaptor for bottle plugs; 3 x plugs for vacuuming of bottles
Special accessories	Part No. 00578813 vacuuming bags, small; Part No. 00578814 vacuuming bags, big
Appliance combinations	Installation of GO/GS/GM/GC directly above the drawer without intermediate shelf
Dishwasher planning	Drawers installed above a dishwasher need a specific niche
Socket positioning	The socket can be planned behind the appliance
Total connected load	0.32 KW
Connection cable	1.50 m, pluggable

Applications and Usage Details

This vacuuming drawer is suitable for vacuuming for sous-vide cooking, vacuuming for fast marinating and flavouring, vacuuming of vacuuming containers outside the chamber and vacuuming of liquids in bottles outside the chamber.

Operation is via touch keys, with a handleless, push-to-open drawer. Three vacuuming levels are available both in the chamber and outside, as well as three heat-sealing levels for different bag materials. The safety glass cover opens automatically after vacuuming, and the non-stick, removable sealing bar and raised platform support convenient handling.

For planning, the niche should be without a back wall. The appliance protrudes 21 mm from the furniture cabinet front. It can be installed with GO/GS/GM/GC appliances directly above without an intermediate shelf, and drawers located above a dishwasher require a specific niche. The socket can be positioned behind the appliance.

Frequently Asked Questions

What is the niche requirement for installing the GV251130 vacuuming drawer?

The vacuuming drawer is integrable in a 14 cm high niche. The niche should be planned without a back wall, and the protrusion from the appliance front to the furniture cabinet is 21 mm.

What vacuum levels does the drawer provide?

There are three vacuuming levels for vacuuming in the chamber with up to a maximum of 99% vacuuming, and three vacuuming levels for vacuuming outside the chamber with up to a maximum of 90% vacuuming.

Which applications is this vacuuming drawer designed for?

It is designed for vacuuming for sous-vide cooking, vacuuming for fast marinating and flavouring, vacuuming of vacuuming containers outside the chamber and vacuuming of liquids in bottles outside the chamber.

What is included with the GV251130 as standard accessories?

Included are 50 small vacuuming bags, 50 big vacuuming bags, one raised vacuuming platform, one adaptor for vacuuming outside the chamber, one vacuuming hose, one adaptor for bottle plugs and three plugs for vacuuming bottles.

Can this vacuuming drawer be combined with other Gaggenau appliances?

Yes. GO, GS, GM and GC appliances can be installed directly above the drawer without an intermediate shelf, according to the planning notes.

Are there special accessories available for vacuuming bags?

Special accessories available as spare parts include Part No. 00578813 for small vacuuming bags and Part No. 00578814 for big vacuuming bags.
