The Gaggenau GV251100 is a vacuuming drawer from the Minimalistic series, designed for integration in a 14 cm high niche. It features a hygienic stainless steel vacuuming chamber with three vacuuming levels for use inside and outside the chamber. Suitable for sous-vide cooking, fast marinating, flavouring, and vacuuming containers and bottles, it offers touch key operation, a handleless push-to-open drawer and flush installation for a streamlined kitchen design.

Key Features

Integrable in 14 cm high niche for seamless installation within the kitchen cabinetry.
Hygienic stainless steel vacuuming chamber with applicable height up to 95 mm.
3 vacuuming levels in the chamber providing up to 99 % vacuuming performance.
3 vacuuming levels outside the chamber delivering up to 90 % vacuuming performance.
Automatic connection recognition for vacuuming outside the chamber for convenient use with accessories.
Vacuuming for sous-vide cooking as a core application of the drawer.
Vacuuming for fast marinating and flavouring of foods, both in the chamber and in containers.
Vacuuming of containers and bottles outside the chamber including liquids in bottles.
Handleless drawer with push-to-open function for a clean, minimalistic appearance.
Touch key operation for simple and direct control of vacuuming and sealing functions.
Net volume of 7 litres and maximum load capacity of 10 kg for versatile use.
3 heat-sealing levels to match different strengths of bag material.
Non-stick, removable sealing bar for easier handling and maintenance.
Safety glass cover that opens automatically after vacuuming.
Raised vacuuming platform, 44 mm, deployable for flexible positioning of items.
Membrane to avoid reflow of liquids during vacuuming outside the chamber.
Drying programme for vacuuming pump to support functional reliability.
Flush installation for a streamlined integration with kitchen fronts.
Utility space in vacuuming chamber of W 210 mm x L 275 mm for convenient bag placement.
Included accessories: small and big vacuuming bags, raised platform, hose, adaptors and bottle plugs.

Technical Specifications

Product name	Vacuuming drawer Gaggenau Minimalistic series
Model code	GV251100
Dimensions	60 x 14 cm
Net volume	7 litres
Maximum load capacity	Max. 10 kg
Applicable chamber height	Up to 95 mm
Vacuuming levels (in chamber)	3 levels, max. 99 %
Vacuuming levels (outside chamber)	3 levels, max. 90 %
Maximum bag size	W 240 mm x L 350 mm
Utility space in chamber	W 210 mm x L 275 mm
Raised vacuuming platform height	44 mm, deployable
Total connected load	0.32 kW
Connection cable	1.50 m, pluggable
Installation type	Flush installation, handleless, push-to-open
Niche requirements	Integrable in 14 cm high niche; plan the niche without back wall
Protrusion to cabinet front	21 mm from appliance front to furniture cabinet
Special accessories (spare parts)	Part No. 00578813 vacuuming bags, small; Part No. 00578814 vacuuming bags, big

Applications, Handling and Installation

Applications

Vacuuming for sous-vide cooking.
Vacuuming for fast marinating and flavouring.
Vacuuming of vacuuming containers outside the chamber.
Vacuuming of liquids in bottles outside the chamber.

Handling and Functions

Touch key operation for controlling vacuuming and sealing.
3 heat-sealing levels for different strengths of bag material.
Sealing bar with non-stick coating, removable.
Safety glass cover opens automatically after vacuuming.
Membrane for avoiding reflow of liquids during vacuuming outside the chamber.
Drying programme for the vacuuming pump.

Installation and Planning Notes

Plan the niche without back wall.
Protrusion from appliance front to furniture cabinet is 21 mm.
Installation of GO/GS/GM/GC directly above the drawer is possible without an intermediate shelf.
Drawers installed above a dishwasher need a specific niche.
The socket can be planned behind the appliance.

Included Accessories

50 x vacuuming bag, small.
50 x vacuuming bag, big.
1 x raised vacuuming platform.
1 x adaptor for vacuuming outside the chamber.
1 x vacuuming hose.
1 x adaptor for bottle plugs.
3 x plugs for vacuuming of bottles.

Frequently Asked Questions

What are the main uses of the GV251100 vacuuming drawer?

It is designed for vacuuming for sous-vide cooking, vacuuming for fast marinating and flavouring, vacuuming of vacuuming containers outside the chamber, and vacuuming of liquids in bottles outside the chamber.

How many vacuuming levels does the drawer offer?

There are 3 vacuuming levels for vacuuming in the chamber with a maximum of 99 % and 3 vacuuming levels for vacuuming outside the chamber with a maximum of 90 %.

What is the maximum size of vacuuming bags that can be used?

The maximum size of vacuuming bags is W 240 mm x L 350 mm.

Does the appliance include vacuuming bags and accessories?

Yes. It includes 50 small vacuuming bags, 50 big vacuuming bags, a raised vacuuming platform, an adaptor for vacuuming outside the chamber, a vacuuming hose, an adaptor for bottle plugs and 3 plugs for vacuuming bottles.

Are additional vacuuming bags available as spare parts?

Yes. Special accessories available as spare parts include Part No. 00578813 vacuuming bags, small, and Part No. 00578814 vacuuming bags, big.

What kind of installation is required for the niche?

The drawer is integrable in a 14 cm high niche, which should be planned without a back wall. The protrusion from the appliance front to the furniture cabinet is 21 mm, and the socket can be planned behind the appliance.
