The Series 7 Contemporary Double DishDrawer™ dishwasher DD60D2HNX9 is designed to be installed under your benchtop with recessed handles for a seamless, streamlined look. Each independent drawer fits full-size dinner plates and holds a true half load, offering seven wash programmes plus Quick, Sanitise and Dry+ modifiers. Flexible racking, quiet operation, efficient performance and Wi-Fi connectivity with the SmartHQ™ app support convenient, effective dishwashing for a variety of loads.

Key Features

Double DishDrawer™ design – Wash one drawer while you load the other, each with room for full-size dinner plates.
Built-under, seamless installation – Designed to be installed under your benchtop with recessed handles and optional custom kickstrip for a flush, streamlined look.
Seven wash programmes – 60 min, Eco, Glassware, Heavy, Light, Medium and Rinse to suit a variety of dishes and soil levels.
Quick, Sanitise and Dry+ modifiers – Quick delivers a faster wash, Sanitise kills 99.9% of bacteria in the final rinse (certified to NSF/ANSI Standard 184), and Dry+ is ideal for plastic dishes.
Flexible racking – Adjustable height, foldable cup racks, fold down and pitch adjustable tines help customise internal shelves for different dishes.
Independent wash drawers – Both drawers operate independently so two different wash cycles can run simultaneously.
True half load capability – Each drawer holds a true half load for small, fast washing that will not waste water.
Quiet performer – Running at a very low decibel rating, with 43 dBA on the standard cycle (top drawer), for low-noise operation.
Efficient performance – Uses the energy it needs without compromising on wash performance, with 54kWh/100 cycles per drawer and 7.8L water per wash cycle per drawer.
Wi-Fi enabled – Works with the SmartHQ™ app for remote control and notifications.
Ease of use – As easy to open and close as kitchen drawers and can be positioned at bench height for easier loading and minimal bending.
SmartDrive™ technology – BLDC motor with simple mechanics for greater reliability and excellent wash performance.
Built-in water softener and fan assisted drying – For optimised washing and drying results.
Flood protection – Designed to help protect against leaks.
Included accessories – Cutlery basket, knife clip and multipurpose clip, and kickstrip.

Technical Specifications

Model	DD60D2HNX9
Series	Series 7 \| Contemporary Double DishDrawer™ Dishwasher
Height	820 – 880 mm
Width	599 mm
Depth	573 mm
Place settings (total)	12 place settings (6 place settings per drawer)
Maximum plate size	Accommodates round plates up to 280mm
Energy rating	E
Energy usage	54kWh/100 cycles per drawer
In-use energy carbon emissions estimate	10.5kgCO2e/100 cycles per drawer
Water usage per wash cycle	7.8L per drawer
Noise level (standard cycle top drawer)	43 dBA
Motor type	BLDC with SmartDrive™ technology
Power supply voltage	220 – 240V
Supply frequency	50Hz
Amperage	10A
Water pressure	100kPa – 1000kPa
Water supply connection	3/4' BSP (20mm) Connector Water Inlet Hose
Wash programmes	7 (60 min, Eco, Glassware, Heavy, Light, Medium, Rinse)
Wash modifiers	3 (Dry+, Quick, Sanitise)
Included accessories	Cutlery basket, knife clip, multipurpose clip, kickstrip
Controls	End of cycle beeps, energy saving delay start (up to 12 hours), keylock, rinse aid indicator light, time remaining LED display, smart appliance
Features	Built-in water softener, fan assisted drying, flood protection, flow through detergent dispenser, quiet operation, SmartDrive™ technology
SKU	82892

Additional Details and Usage

Installation and Fit

This built-under Double DishDrawer™ dishwasher is designed to be installed flush under your benchtop, with the option of a custom kickstrip to minimise gaps. Recessed handles support a streamlined appearance and alignment with other Fisher & Paykel kitchen appliances.

Loading and Flexibility

Each drawer can hold a true half load and accommodates round plates up to 280mm. Flexible racking, including adjustable height and foldable cup racks, fold down tines and pitch adjustable tines, helps you arrange dishes, glassware and pots to suit your needs. The drawers can be positioned at bench height to reduce bending and make loading and unloading easier.

Programmes and Modifiers

Seven wash programmes are available: 60 min, Eco, Glassware, Heavy, Light, Medium and Rinse. Three modifiers allow further customisation:

Quick – Delivers a faster wash while maintaining performance.
Sanitise – Provides extra protection by killing 99.9% of bacteria in the final rinse (certified to NSF/ANSI Standard 184).
Dry+ – A drying option that is particularly suitable for plastic dishes.

Independent and Half-Load Washing

Both drawers operate independently, allowing you to select different wash programmes at the same time to suit varying loads – from fine glass and crystal to heavily soiled pots and pans. Each drawer’s true half load capacity enables small, fast washes without wasting water.

Controls and Smart Features

User-friendly controls include end of cycle beeps, an energy saving delay start option of up to 12 hours, keylock, rinse aid indicator light and a time remaining LED display. The appliance is Wi-Fi enabled and works with the SmartHQ™ app for remote control and notifications.

Performance and Protection

Quiet operation, with a noise level of 43 dBA on the standard cycle (top drawer), combines with SmartDrive™ technology and a BLDC motor for excellent wash performance and reliability. Built-in water softener, fan assisted drying and flow through detergent dispenser support effective cleaning, while flood protection is designed to help safeguard your kitchen.

Frequently Asked Questions

How many place settings can this Double DishDrawer™ hold?

The dishwasher holds 12 place settings in total, with 6 place settings per drawer.

Can I run different wash programmes in each drawer at the same time?

Yes. Both drawers operate independently, so you can choose different wash programmes for each drawer and run them simultaneously.

What is the benefit of the Sanitise modifier?

The Sanitise option provides extra protection by killing 99.9% of bacteria in the final rinse and is certified to NSF/ANSI Standard 184.

Is this dishwasher suitable for plastic items?

Yes. The Dry+ setting is described as perfect for plastic dishes, helping to improve drying performance on these items.

How quiet is the Double DishDrawer™ during operation?

It runs at a very low decibel rating, with a noise level of 43 dBA on the standard cycle for the top drawer.

What are the energy and water usage figures?

Energy usage is 54kWh per 100 cycles per drawer, with an in-use energy carbon emissions estimate of 10.5kgCO2e per 100 cycles per drawer. Water usage is 7.8L per wash cycle per drawer.

DD60D2HNX9

Fisher & Paykel Series 7 DD60D2HNX9 Double Dishdrawer
